TDK Film Capacitor B32522N6474J000 470 nF 450V AC 450 V DC Through Hole 2 Pin 15mm Pitch B32522N6474J000

TDK B32522N6474J000 is a high-quality film capacitor designed for through-hole mounting applications, offering a capacitance of 470 nF with rated voltages of 450 V AC and 450 V DC. This capacitor is engineered utilizing stacked-film and wound technology housed in a plastic case sealed with epoxy resin, ensuring excellent electrical and mechanical performance.

Its construction and design comply with the automotive AEC-Q200 Rev D standard, granting high pulse strength and reliability essential for automotive electronics as well as demanding industrial applications. The capacitor is suitable for general purpose blocking, coupling, decoupling, bypassing, and radio frequency interference (RFI) suppression.

With a compact form factor measuring 18 mm in length, 8.5 mm in width, and 14.5 mm in height, along with a 15 mm lead pitch and 0.8 mm lead diameter, it is optimized for easy through-hole PCB mounting. The product operates reliably up to 125°C maximum temperature, accommodating high-temperature environments.

This component adheres to international standards including RoHS and UL, underscoring its compliance with global safety and environmental regulations. 2-pin configuration with 15 mm lead pitch for robust mounting. High pulse strength and contact reliability suited for automotive use.

Plastic casing with epoxy resin for enhanced durability and insulation. Compact dimensions supporting space-efficient PCB layouts. Capacitance of 470 nF suitable for a wide range of electronic circuits. Meets RoHS and UL standards for quality assurance.

Maximum operating temperature rating of 125°C.

Typical applications include usage in industrial electronics, automotive circuits, power supplies, and general-purpose passive filtering. This capacitor’s robust design and adherence to automotive standards make it a trusted choice for engineers seeking reliable and durable film capacitors.
