Wurth Elektronik WR-MPC3 Series Vertical Surface PCB Header, 24 Contact(s), 3 mm Pitch, 2 Row, Shrouded MPC3

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-MPC3 Series Vertical Surface PCB Header, 24 Contact(s), 3 mm Pitch, 2 Row, Shrouded MPC3

Name: Wurth Elektronik WR-MPC3 Series Vertical Surface PCB Header, 24 Contact(s), 3 mm Pitch, 2 Row, Shrouded MPC3
Brand: Wurth Elektronik
SKU: 402968
Price: 3.85 USD
Availability: InStock



Category PCB Header Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	250V
Brand	Wurth Elektronik
Orientation	Vertical
Current	5A
Model	MPC3
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Copper Alloy
Series	WR-MPC3
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	3mm
Contact Plating	Tin
Number of Contacts	24
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

The header features a dual row configuration with 2 rows for enhanced connectivity.
Contacts are made of copper alloy with tin plating to ensure durability and conductivity.
Housing is made from Liquid Crystal Polymer for high temperature and mechanical stability.
Rated for 5 A current and 250 V voltage, suitable for standard PCB applications.
Designed for vertical surface mounting with solder termination type.
Operating temperature ranges from -40°C to 105°C, supporting various environmental conditions.
The shrouded design offers protection and correct connector mating.
Manufactured in Taiwan, Province Of China, ensuring quality compliance.

Product Description

Wurth Elektronik MPC3 vertical surface PCB header, model MPC3, features 24 male contacts arranged in 2 rows with a 3 mm pitch. It is designed for surface mounting and offers a shrouded connection system ideal for wire-to-board configurations. The housing, made of Liquid Crystal Polymer, provides excellent mechanical strength and high-temperature resistance.

This PCB Header is rated for a maximum current of 5 A and voltage up to 250 V, making it suitable for a broad range of industrial and electronic PCB applications. The copper alloy contacts with tin plating ensure low contact resistance and corrosion protection, while the solder termination type facilitates stable and secure assembly.

Operating temperature ranges from -40°C to 105°C, enabling reliable performance in harsh environments. The vertical orientation of this header supports efficient board layout and connector assembly. The shrouded design aids in preventing mis-mating and protects the contacts during handling and usage.

This product is manufactured in Taiwan, Province Of China, and adheres to strict quality standards, although it does not specify certifications such as RoHS or UL approvals. The robust construction and consistent electrical properties make it ideal for applications in industrial electronics, power supplies, telecommunications, and embedded systems.

The header features a dual row configuration with 2 rows for enhanced connectivity. Contacts are made of copper alloy with tin plating to ensure durability and conductivity. Housing is made from Liquid Crystal Polymer for high temperature and mechanical stability.

Rated for 5 A current and 250 V voltage, suitable for standard PCB applications. Designed for vertical surface mounting with solder termination type. Operating temperature ranges from -40°C to 105°C, supporting various environmental conditions.

The shrouded design offers protection and correct connector mating. Manufactured in Taiwan, Province Of China, ensuring quality compliance.
