DiodesZetex 2 A NPN Bipolar Transistor 70 V Surface Mount SOT-223 Package FZT692BTA

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 2 A NPN Bipolar Transistor 70 V Surface Mount SOT-223 Package FZT692BTA

Name: DiodesZetex 2 A NPN Bipolar Transistor 70 V Surface Mount SOT-223 Package FZT692BTA
Brand: DiodesZetex
SKU: 394601
Price: 20.22 USD
Availability: InStock



Category Bipolar Transistors Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	1.65mm
Length	6.7mm
Model	FZT692BTA
Width	3.7mm
Mount Type	Surface
Series	FZT692B
Maximum Operating Temperature	150°C
Package Type	SOT-223
Minimum Operating Temperature	-55°C
Pin Count	4
Maximum Collector Emitter Voltage Vceo	70V
Minimum DC Current Gain hFE	150
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	70V
Automotive Standard	AEC-Q100, AEC-Q101, AEC-Q200
Maximum Power Dissipation Pd	2W
Maximum DC Collector Current Idc	2A
Transistor Configuration	Single
Maximum Transition Frequency ft	150MHz

Key Features

This transistor features a maximum power dissipation of 2 W and transition frequency of 150 MHz.
It operates reliably within temperatures ranging from -55°C to 150°C.
The device provides a minimum DC current gain (hFE) of 150 and has voltage ratings for emitter-base and collector-base of 5 V and 70 V respectively.
The compact dimensions of 6.7 mm length, 3.7 mm width, and 1.65 mm height support efficient PCB layout.
Designed to automotive standards AEC-Q100, AEC-Q101, and AEC-Q200, ensuring robust performance in demanding environments.

Product Description

DiodesZetex FZT692BTA is a high-performance single NPN bipolar transistor designed for electronic applications requiring moderate power and frequency capabilities. It supports a maximum DC collector current of 2 A and a maximum collector-emitter voltage of 70 V, making it suitable for switching and amplification in power control circuits.

The transistor is packaged in a surface-mount 4-pin SOT-223 package which offers enhanced power dissipation due to its larger thermal pad compared to standard SOT packages. This makes it ideal for compact PCB designs in industrial, automotive, and commercial electronics.

Operating temperature ranges from a minimum of -55°C to a maximum of 150°C, allowing reliable use under harsh environmental conditions. The device meets stringent automotive standards AEC-Q100, AEC-Q101, and AEC-Q200 which assure durability and reliability in vehicle electronics and other high-reliability applications.

Key electrical parameters include a minimum DC current gain (hFE) of 150, maximum power dissipation of 2 W, and a transition frequency (ft) of 150 MHz, providing efficient high-speed switching performance. The transistor polarity is NPN with specified limits on emitter-base voltage of 5 V and collector-base voltage of 70 V.

Physical dimensions of 6.7 mm length, 3.7 mm width, and 1.65 mm height allow ease of integration into surface-mount PCB assemblies. The 4-pin configuration facilitates stable mounting and electrical connections.

This transistor is suited for use in electronic circuit switching, amplification, automotive electronics, power management, and other industrial applications. Compliance with automotive AEC standards endorses suitability for safety-critical vehicle and transportation systems.

Its package and electrical characteristics make it an excellent choice for designers requiring reliable, compact semiconductor devices. Explore the Electronics & Electricals category for more semiconductors and Bipolar Transistors that meet demanding industrial and commercial application requirements.
