Vishay Standard Recovery Silicon Diode 800 V 35 A 2-Pin DO-203AB VS-1N3766R
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 17.4mm |
| Brand | Vishay |
| Height | 22.9mm |
| Length | 20.02mm |
| Model | VS-1N3766R |
| Width | 17.35mm |
| Mount Type | Screw |
| Maximum Operating Temperature | 190°C |
| Package Type | DO-203AB |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 35A |
| Peak Reverse Repetitive Voltage Vrrm | 800V |
| Diode Configuration | Stud Anode |
| Rectifier Type | Silicon |
| Peak Reverse Current Ir | 4mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 400A |
| Maximum Forward Voltage Vf | 1.8V |
| Vishay 800 V 40 A Diode Switching 2-Pin DO-203ABBrand | Vishay |
Key Features
- This diode features a maximum continuous forward current of 35 A for reliable high-current performance.
- The peak reverse repetitive voltage rating is 800 V ensuring robust voltage blocking capability.
- It has a standard DO-203AB package with a stud anode diode configuration.
- Designed to operate in a wide temperature range from -65°C up to 190°C, ensuring durability in harsh environments.
- Peak non-repetitive forward surge current of 400 A supports transient load handling.
- The maximum forward voltage drop is 1.8 V, contributing to efficient power conversion.
- The diode uses a screw mount type package for secure installation.
- It is suitable for numerous industrial and electronic applications requiring standard recovery rectifiers.
Product Description
Vishay VS-1N3766R Standard Recovery Silicon Diode in a 2-Pin DO-203AB package supports a maximum continuous forward current of 35 amperes and peak reverse repetitive voltage of 800 volts. It is designed to provide high efficiency and reliability in power rectification applications, ideal for use in industrial electronics, power supplies, and related electronic components.
The diode configuration features a stud anode which facilitates easy mounting and robust electrical connection. This power diode supports operation across a wide temperature range from -65°C to 190°C, making it suitable for demanding environments.
Its maximum forward voltage of 1.8 volts ensures efficient power handling, while the peak non-repetitive forward surge current rating of 400 amperes guarantees resilience to transient current loads. The physical dimensions, including a height of 22.9 mm, length of 20.02 mm, width of 17.35 mm, and diameter of 17.4 mm, make it compact and easily integrated within various assemblies.
It is a standard recovery type diode typically used in discrete semiconductor roles within industrial electronics systems and power connectors.
The product does not carry specific standards or automotive certifications yet provides consistent performance for industrial, laboratory, manufacturing, and electrical engineering use cases. Its screw mounting package type ensures secure and stable installation in applications.
This diode supports a continuous forward current up to 35 A for high-power applications. Rated for peak reverse repetitive voltage of 800 V, suitable for voltage blocking. Designed for wide operational temperature range from -65°C to 190°C.
Compact 2-pin DO-203AB package with stud anode configuration. Maximum forward voltage drop of 1.8 V for efficiency. Peak surge current of 400 A for transient protection. Screw mount package type for reliable installation.
Compact dimensions suited for integration: 22.9 mm height, 20.02 mm length. Explore more Vishay semiconductor diodes and power rectifier components at EnvMart for industrial and laboratory setups.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this diode is 35 A.
This unit can operate in a wide temperature range from -65°C to 190°C.
The maximum forward voltage drop is 1.8 V.
It uses a standard DO-203AB package with a stud anode configuration.
The peak non-repetitive forward surge current rating is 400 A.
The diode has a height of 22.9 mm, length of 20.02 mm, width of 17.35 mm, and a diameter of 17.4 mm.
It supports a screw mount type for secure installation.
The product does not carry specific standards or automotive certifications.
The country of origin for this model is India.
