TDK Film Capacitor 100 nF 200V AC 520V DC Through Hole 2-Pin B32671P5104K000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 100 nF 200V AC 520V DC Through Hole 2-Pin B32671P5104K000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	11mm
Length	13mm
Model	B32671P5104K000
Width	5mm
Mount Type	Through Hole
Series	B32671P
Maximum Operating Temperature	125°C
Capacitance	100nF
Standards/Approvals	RoHS, UL
Pin Count	2
Rated AC Voltage	200V ac
Rated DC Voltage	520V dc
Lead Pitch	10mm
Lead Diameter	0.6mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Constructed with metallised polypropylene film and epoxy resin sealing for enhanced durability.
Compact dimensions measuring 13mm length, 11mm height, and 5mm width.
Through hole mounting with 2 pins having 10mm lead pitch and 0.6mm lead diameter.
Certified to RoHS and UL standards with automotive standard AEC-Q200 Rev D compliance.
Operates safely at maximum temperature of 125°C with high-frequency AC and peak current capability.

Product Description

The TDK B32671P5104K000 film capacitor is a precision metallised polypropylene capacitor designed for industrial and electronic applications requiring reliable capacitance and voltage stability. With a capacitance of 100 nF, it supports rated AC voltage of 200V and DC voltage up to 520V, making it suitable for high voltage and high frequency circuits.

Its through hole mount type and 2-pin configuration with a lead pitch of 10mm facilitate easy PCB insertion and soldering. The capacitor housing uses a plastic case conforming to UL 94 V-0 standards and epoxy resin sealing, enhancing durability and resistance to environmental impacts.

This capacitor complies with stringent automotive standard AEC-Q200 Rev D, ensuring dependable operation in automotive and industrial environments. It provides excellent self-healing properties and high ripple current capabilities for robust performance in power factor correction and other applications.

The compact size featuring 13mm length, 11mm height, 5mm width, and 0.6mm lead diameter enables component density optimization on circuit boards. Rated for continuous operation up to 125°C, it is suitable for demanding electrical and electronic industrial use cases.

Metallised polypropylene film construction with epoxy resin sealing for durability. High voltage ratings of 200V AC and 520V DC for versatile electrical circuits. Automotive certified with AEC-Q200 Rev D standard for rugged applications.

Ideal for power factor correction and high-frequency AC capacitor needs. Compact form factor with through hole mounting and 2-pin design.

This TDK Film Capacitor is widely used in industrial electronics, power supplies, automotive electronics, and laboratory equipment for filtering, coupling, and timing applications. It combines reliability, compact size, and high electrical ratings essential for modern electronic systems.
