Wurth Elektronik Polypropylene Film Capacitor X2 680nF 310V dc/ac Through Hole Mount 890334026020CS

Wurth Elektronik 890334026020CS polypropylene film capacitor is a high-reliability electronic component designed for interference suppression and filtering applications in industrial and commercial electrical systems. It features a capacitance of 680nF with a tolerance of ±10%, suitable for precise signal conditioning and filtering.

This capacitor supports a rated voltage of 310 V for both DC and AC, assuring safe operation under varying electrical stresses. It is mounted via the through-hole method with a lead pitch of 22.5mm, accommodating easy and secure installation on PCBs.

Constructed with metallized polypropylene film technology from the WCAP-FTXX series, this capacitor exhibits excellent self-healing properties to enhance durability under voltage spikes. The unit operates reliably within a temperature range of -40 °C to +105 °C and is encapsulated in a self-extinguishing material meeting UL94V-0 specifications, ensuring safety in demanding environments.

Key physical dimensions include a length of 26mm, height of 15mm, and a width of 7.5mm, with lead diameter 0.8mm and lead length 4mm, designed for standard PCB mounting configurations. The dissipation factor of 0.7% reflects low energy loss and high efficiency in performance.

Widely used in filter circuits, interference suppression coils, and EMI filters, this capacitor conforms to CQC, cULus, ENEC, and VDE standards, making it suitable for critical applications such as safety and power supplies in industrial, commercial, and consumer electronics.

Capacitance of 680 nanofarads ensures stable filter performance. Rated for 310 V DC and 310 V AC voltage for diverse electrical applications. Mounted using through hole technique with a pitch of 22.5 mm for secure installation.

Temperature range from -40°C to +105°C for reliable operation in varied environments. Plastic encapsulation meets UL94V-0 standard for safety and self-extinguishing material. Dissipation factor of 0.7% indicates efficient dielectric characteristics.

Applications include safety filters, interference suppression, and EMI filtering. Lead specifications: 4 mm length, 0.8 mm diameter with solder terminal type. Dimension specifics: 26 mm length, 15 mm height, and 7.5 mm width.

Meets standards including CQC, cULus, ENEC, and VDE certifications.

This product is ideal for electrical engineers and technicians requiring high-quality, reliable Film Capacitors for safety and EMI suppression tasks in industrial, manufacturing, and electronic device production environments. EnvMart offers detailed product specifications to aid design and application workflows.
