Wurth Elektronik WR-MPC3 Series 3.0mm Pitch Straight Through Hole PCB Header, 10 Contacts, 2 Row, Shrouded MPC3

Wurth Elektronik MPC3 series is a high-quality 3.0mm pitch, straight through hole PCB header designed for reliable wire-to-board connections in various industrial and electronic applications.

The component features a durable liquid crystal polymer housing rated UL94-V0 in black, providing excellent flame retardance and mechanical stability.

This dual-row, shrouded male header includes 10 tin plated copper alloy contacts ensuring efficient electrical connectivity with current handling capacity of 5 amperes and rated voltage of 250 volts.

Designed for solder termination, the header has a tail pin length of 3.18mm, facilitating secure through-hole mounting on printed circuit boards.

Operating reliably across a wide temperature range from -40°C to 105°C, this product suits demanding environments such as industrial controls, telecommunications, and instrumentation hardware.

The MPC3 header mates seamlessly with complementary WR-MPC3 3.0mm dual row female receptacle housings, enabling versatile connector configurations. The shrouded design adds protection against mechanical damage and accidental contact, enhancing durability and safety in PCB assemblies.

The header is designed for wire-to-board connection applications. It features a robust liquid crystal polymer housing with UL94-V0 black rating. Contacts are made from tin plated copper alloy ensuring reliable conductivity.

Suitable for currents up to 5A and voltages up to 250V. Termination is by solder, with a 3.18mm tail pin length for secure mounting. Operating temperature range from -40°C to 105°C supports wide industrial environments. The male connector is vertical mount with kinked pins and board guides for easy insertion.

It mates with WR-MPC3 3.0mm dual row female receptacle housings for complete assembly. The component is shrouded for enhanced protection and connection integrity. The product comes new, ideal for electronic manufacturing and PCB assembly applications.

This Wurth Elektronik PCB header is well-suited for electronics manufacturing, industrial instrumentation, power connectors, and telecommunications equipment. Explore the full Wurth Elektronik range in PCB Headers at EnvMart for compatible components and high-quality connector solutions.
