Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header 8 Contacts 4.2 mm Pitch 2 Row Shrouded MPC4

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header 8 Contacts 4.2 mm Pitch 2 Row Shrouded MPC4

Name: Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header 8 Contacts 4.2 mm Pitch 2 Row Shrouded MPC4
Brand: Wurth Elektronik
SKU: 379306
Price: 1.53 USD
Availability: InStock



Category PCB Headers Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	Wurth Elektronik
Orientation	Right Angle
Current	69A
Model	MPC4
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Nickel
Series	WR-MPC4
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	4.2mm
Contact Plating	Tin
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.5mm

Key Features

Constructed with durable polyamide housing for robust performance.
Features nickel contact material with tin plating for excellent conductivity.
Designed for through hole mounting with solder termination.
Operates reliably in temperatures ranging from -40°C to 105°C.
Supports up to 600V voltage rating and 69A current rating for demanding applications.
Right angle orientation facilitates space-saving PCB layouts.
Includes a 3.5mm tail pin length ensuring secure board connection.
Shrouded to prevent accidental short circuits and improve safety.

Product Description

Wurth Elektronik MPC4 Series Right Angle Through Hole PCB Header offers a dual row configuration with 8 male contacts spaced at 4.2 mm pitch. This shrouded header connector is constructed with a white nylon 66 UL94-V0 polyamide insulator housing that provides excellent durability and flame resistance.

The nickel contacts are tin plated to ensure reliable electrical performance and durability over extended use. Designed for through hole mount, the header features a right angle orientation which aids in compact designs where board space is limited.

The product operates effectively in environments ranging between -40°C and 105°C and can handle currents up to 69A with a voltage rating of 600V. The solder termination type and 3.5 mm tail pin length make it suitable for secure and stable PCB assembly, supporting a wire-to-board connector system.

This component is ideal for a wide array of industrial and commercial electronics assembly tasks, including power connectors in control units, factory automation, and electronic testing equipment. Its shrouded design improves safety by reducing the risk of short circuits.

Constructed with durable polyamide housing for robust performance. Features nickel contact material with tin plating for excellent conductivity. Designed for through hole mounting with solder termination. Operates reliably in temperatures ranging from -40°C to 105°C.

Supports up to 600V voltage rating and 69A current rating for demanding applications. Right angle orientation facilitates space-saving PCB layouts. Includes a 3.5mm tail pin length ensuring secure board connection. Shrouded to prevent accidental short circuits and improve safety.

Complies with industry quality standards, ensuring dependable use.

Choose Wurth Elektronik MPC4 Series for dependable, high quality PCB header connectors to enhance reliability and performance in your electronic designs. Browse EnvMart’s Electronics & Electricals category for more connector solutions and industrial components.
