Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 6 Contact, 4.2 mm Pitch, 2 Row, Shrouded MPC4

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 6 Contact, 4.2 mm Pitch, 2 Row, Shrouded MPC4

Name: Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 6 Contact, 4.2 mm Pitch, 2 Row, Shrouded MPC4
Brand: Wurth Elektronik
SKU: 379295
Price: 1.06 USD
Availability: InStock



Category PCB Headers Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	600V
Brand	Wurth Elektronik
Orientation	Straight
Current	69A
Model	MPC4
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	WR-MPC4
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	4.2mm
Contact Plating	Tin over Nickel
Number of Contacts	6
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.5mm

Key Features

Features a dual row, 6-contact male header with a 4.2 mm pitch for precise PCB mounting.
Constructed with polyamide housing providing durability and electrical insulation.
Contact material made from copper alloy with tin over nickel plating for corrosion resistance.
Supports a maximum operating current of 69A and voltage rating of 600V.
Designed for through-hole mounting and straight orientation, ensuring reliable wire-to-board connections.
Temperature operating range from -40°C to 105°C suitable for varied industrial environments.
Tail pin length of 3.5 mm for secure solder termination.
Shrouded connector system enhances protection against shorts and mechanical damage.

Product Description

Wurth Elektronik MPC4 series straight through hole PCB Headers feature a 6-contact, dual row male connector with a 4.2 mm pitch, designed for robust wire-to-board electrical connections. This series utilizes a high-quality polyamide housing that offers excellent durability and electrical insulation compliance with industrial standards.

The contacts are made of copper alloy and plated with tin over nickel to provide exceptional conductivity and resistance to corrosion. The connector supports a maximum current rating of 69A and a voltage rating of 600V, suitable for demanding power distribution applications.

With a temperature tolerance from -40°C to 105°C, this header is engineered to operate reliably in a wide range of industrial, manufacturing, and electronic assembly environments. The straight orientation and through-hole mount type facilitate easy PCB assembly and mechanical stability.

The shrouded design prevents accidental shorts and protects contacts from mechanical damage, improving safety and longevity of PCB assemblies. Each tail pin measures 3.5 mm in length to ensure a secure solder connection, enhancing both electrical performance and mechanical integrity.

Dual row, 6-contact male header with 4.2 mm pitch. Polyamide housing ensures durability and insulation. Copper alloy contacts plated with tin over nickel for corrosion resistance. Rated for 69A current and 600V voltage. Suitable for industrial temperatures from -40°C to 105°C.

Through-hole mount and straight orientation for robust PCB connection. Shrouded system protects contacts and prevents shorts. 3.5 mm tail pin length for secure soldering.

This Wurth Elektronik WR-MPC4 series PCB header connector is ideal for use in electronic components manufacturing, power distribution modules, industrial automation equipment, and other commercial and industrial electrical assemblies. Its design meets the needs of engineers demanding reliable, high-current, and secure PCB connectors.
