Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header, 4 Contact(s), 4.2 mm Pitch, 2 Row, Shrouded MPC4

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header, 4 Contact(s), 4.2 mm Pitch, 2 Row, Shrouded MPC4

Name: Wurth Elektronik WR-MPC4 Series Right Angle Through Hole PCB Header, 4 Contact(s), 4.2 mm Pitch, 2 Row, Shrouded MPC4
Brand: Wurth Elektronik
SKU: 379290
Price: 1.07 USD
Availability: InStock



Category PCB Headers Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	Wurth Elektronik
Orientation	Right Angle
Current	69A
Model	MPC4
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Nickel
Series	WR-MPC4
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	4.2mm
Contact Plating	Tin
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.5mm

Key Features

Features a dual row design with 2 rows for efficient PCB connections.
Constructed with polyamide housing for durability and UL94-V0 flame retardance.
Right angle orientation for space-saving placement on PCBs.
Contacts are male, nickel material with tin plating for corrosion resistance.
Designed for 600V voltage and 69A current carrying capacity.
Has a tail pin length of 3.5mm suitable for through-hole mounting.
Shrouded style provides extra protection against shorts and ensures secure mating.
Operating temperature ranges from -40°C to 105°C for broad environmental use.

Product Description

Wurth Elektronik MPC4 Series is a precision-engineered right angle through hole PCB header connector designed for reliable electrical connections in demanding power connector applications. This model features 4 male contacts arranged in 2 rows with a 4.2 mm pitch, ideal for wire-to-board mounting. The housing is made of high-quality polyamide with UL94-V0 flame retardance for superior safety and durability.

The contacts are constructed from nickel with tin plating, ensuring excellent corrosion resistance and solderability. With a voltage rating of 600V and current capacity of 69A, these headers are suitable for high power electronic assemblies. Their shrouded design protects the contacts from accidental short circuits and ensures secure mating with matching female receptacles.

Operating temperature range from -40°C up to 105°C allows usage in a variety of industrial, manufacturing, and commercial environments that require reliable, long-lasting connections. The 3.5 mm tail pin length facilitates sturdy through hole mounting, ensuring mechanical stability on PCBs.

Features a dual row 4.2 mm pitch with 4 contacts for compact, high-density connections. Polyamide housing with flame retardant UL94-V0 rating for electrical safety. Nickel contacts with tin plating provide durability and corrosion resistance.

Shrouded connector design enhances protection and connection reliability. Rated for 600V and 69A, suitable for demanding power applications. Wide operating temperature range supports diverse industrial use cases. Right angle orientation saves PCB space and improves layout efficiency.

Solder termination type for secure electrical and mechanical connection. Wire-to-board connector system commonly used in power connectors. This product is commonly used in electronic assemblies for industrial, manufacturing, and commercial power distribution applications.

Explore the full Wurth Elektronik range and other PCB Headers and Power Connectors on EnvMart for quality assured industrial components.
