Wurth Elektronik WR-MPC4 Series Straight Through Hole 4 Contact Dual Row Shrouded PCB Header 4.2 mm Pitch MPC4

Wurth Elektronik MPC4 series straight through hole PCB header MPC4 is designed for high current wire-to-board applications requiring a reliable dual row male connector. Featuring a 4.2 mm pitch and 4 contacts, this connector provides robust electrical connections with durability ensured by a polyamide housing and tin-plated copper alloy contacts.

The shrouded connector style enhances mechanical reliability and protection, while the through hole mount type enables secure soldering onto circuit boards with a tail pin length of 3.5 mm. Rated for 69A current and a maximum voltage of 600V, it performs reliably in diverse industrial and electronic settings.

Operating temperature ranges from -40°C to 105°C make this connector suitable for use in harsh environments, including industrial controls, power distribution modules, and manufacturing equipment. The connector is designed without additional industry approvals but meets UL94-V0 flammability standards for safety.

The product is made in Taiwan, Province of China, and is ideal for applications requiring secure, durable male connections in electronic assemblies, power connectors, and PCB header systems.

Dual row configuration with 4 contacts and 4.2 mm pitch. Polyamide housing and tin-plated copper alloy contacts. Shrouded design ensures secure mating and protection. Rated for 69A current and 600V voltage maximum. Through hole mount for solder termination with 3.5 mm tail pin length.

Operating temperature range: -40°C to 105°C. Wire-to-board connector system suitable for power applications. UL94-V0 compliant housing material. Manufactured in Taiwan, Province of China. Explore a wide range of PCB Headers and connectors at EnvMart for all your electronic component needs.
