Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header 3 Contacts 4.2mm Pitch 1 Row Shrouded MPC4

Wurth Elektronik MPC4 Series Straight Through Hole PCB Header, model MPC4, is engineered for robust and reliable wire-to-board connections. This single-row male PCB header features 3 contacts spaced at 4.2mm pitch, suitable for power connectors and electronic applications demanding high current and voltage ratings.

Constructed with a polyamide housing material that offers excellent insulation and thermal stability, the header is designed to withstand operating temperatures ranging from -40°C to 105°C. The copper alloy contacts are tin plated, ensuring long-lasting electrical conductivity and resistance to corrosion.

Its through-hole mount type and straight orientation allow for easy and secure soldering on PCBs. The tail pin length of 3.5mm facilitates reliable solder connections, enhancing mechanical and electrical stability. With a current rating of 69A and voltage rating of 600V, this header is ideal for demanding power electronics and industrial applications.

The shrouded design provides protection against accidental contact and ensures proper mating with corresponding WR-MPC4 single row plug style receptacle housings, increasing safety and performance reliability.

This component is widely used in electronic, industrial, and manufacturing environments for power distribution and connector interfaces. Suitable for PCB connectors and wire housing solutions, it meets common industrial standards despite having no specific certifications.

Features a single-row, straight through-hole mounting style for secure PCB attachment. Made with polyamide housing for strong insulation and durability. Copper alloy male contacts with tin plating ensure excellent conductivity and corrosion resistance.

Rated for a maximum operating voltage of 600V and current up to 69A. Operates reliably within a temperature range from -40°C to 105°C. Tail pin length is 3.5mm for effective soldering. Mates with WR-MPC4 series plug style receptacle housings.

Complies with no specific certifications but meets required industrial connection standards. Explore more Wurth Elektronik PCB Headers and connectors on EnvMart for trusted quality and performance in power connector solutions.
