Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 3 Contacts, 4.2 mm Pitch, 1 Row, Shrouded MPC4

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 3 Contacts, 4.2 mm Pitch, 1 Row, Shrouded MPC4

Name: Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 3 Contacts, 4.2 mm Pitch, 1 Row, Shrouded MPC4
Brand: Wurth Elektronik
SKU: 379286
Price: 1.55 USD
Availability: InStock



Category PCB Headers Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	Wurth Elektronik
Orientation	Straight
Current	69A
Model	MPC4
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	WR-MPC4
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	4.2mm
Contact Plating	Tin
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.5mm

Key Features

Rated for a maximum current of 69 A with a voltage rating of 600 V.
Constructed with polyamide housing and shrouded design for enhanced safety.
Features copper alloy contacts plated with tin for reliable conductivity.
Operates between -40°C and 105°C temperature range ensuring robust performance.
Tail pins measure 3.5 mm length optimized for solder termination.
Designed to mate with matching WR-MPC4 4.20 mm pitch plug style receptacle housings.
Offers a single row, male contact gender configuration oriented straight for PCB mounting.
Meets UL94-V0 flammability rating for the white nylon 66 insulator.

Product Description

Wurth Elektronik MPC4 is a WR-MPC4 series single row straight through hole PCB header consisting of 3 male contacts spaced at a 4.20 mm pitch suitable for wire-to-board connector systems.

This connector features a polyamide (nylon 66) housing with UL94-V0 rating providing flame retardancy and durability during industrial and electronic applications. The contacts are stamped from copper alloy and plated with tin, delivering excellent electrical conductivity and corrosion resistance for dependable signal and power transmission.

Designed for through hole mounting on printed circuit boards, the MPC4 header operates under a broad temperature range of -40°C to 105°C and supports currents up to 69 A with a voltage rating of 600 V, making it compatible for power connector applications.

The tail pins extend 3.5 mm for effective soldering termination and the shrouded housing design enhances safety by protecting the contacts from mechanical damage and accidental shorting.

This connector mates with WR-MPC4 single row plug style receptacle housings enabling versatile modular assembly options in power electronics and control systems.

Common use cases include industrial equipment, power distribution assemblies, control panels, and electronic device manufacturing where robust and reliable PCB connectors with a standard 4.20 mm pitch are required.

Rated for 69 A current carrying capacity and 600 V voltage rating. Polyamide insulator with UL94-V0 flame retardant rating. Straight orientation, shrouded housing for enhanced durability and safety. 3 contacts, male tail pins with 3.5 mm length for solder termination.

Designed for through hole PCB mounting and wire-to-board connection systems. Operating temperature range of -40°C to 105°C suitable for industrial environments. Copper alloy contacts plated with tin for corrosion resistance and conductivity.

Mates with MPC4 series single row plug receptacle connectors. Explore the full range of Wurth Elektronik connectors and components available at EnvMart for your electronic assembly and industrial power connector needs.
