Wurth Elektronik WR-BHD Series Straight Through Hole 2 Row PCB Header, 14 Contacts, 2.54 mm Pitch, Shrouded 61201422821

Wurth Elektronik 61201422821 WR-BHD Series Straight Through Hole PCB Header is a highly reliable wire-to-board connector designed for industrial and electronic applications. Featuring 14 contact points arranged in 2 rows with a pitch of 2.54 mm, this header ensures precise and secure PCB connections.

The durable polybutylene terephthalate housing offers excellent resistance to heat and mechanical stress, supporting operating temperatures from -40°C to 125°C. Gold-plated copper alloy contacts provide low contact resistance and excellent conductivity, rated for 3A current and 250V voltage, making it suitable for power distribution on circuit boards.

This shrouded header design includes locking levers that provide stable and secure mating connections, reducing the risk of accidental disconnection in demanding environments. The through-hole mount type allows for solid mechanical fixation to the PCB, enhancing durability in industrial, construction, and manufacturing applications.

The WR-BHD series supports multiple configurations, with this specific model featuring straight orientation and male contact gender. It is widely used in automotive electronics, power connectors, and other electronic devices where robust and secure connections are critical.

Designed and manufactured in Taiwan, Province Of China, this product conforms to RoHS compliance and stringent quality standards, although no formal certifications are listed. The connector is designed for through-hole mounting on PCBs with two rows.

Shrouded design ensures secure connections and protection. Contacts are made of copper alloy with gold plating for optimal conductivity. Supports current rating of 3A and voltage up to 250V. Constructed with durable polybutylene terephthalate housing material.

Operates reliably within a temperature range of -40°C to 125°C. Mating products are compatible, facilitating easy integration in wire-to-board systems. Ideal for power and electronic connector applications requiring robust performance.
