Molex Mega-Fit Series Right Angle Through Hole PCB Header 4 Contacts 5.7 mm Pitch 2 Row Shrouded 172064-0004

Molex 172064-0004 Mega-Fit Series Right Angle Through Hole PCB Header is engineered for demanding electronic applications requiring reliable high current connections. Featuring 4 male contacts spaced at 5.7 mm pitch in two rows, this shrouded PCB header connector is designed to handle up to 23 A current per circuit, supporting robust electronic power transmission.

The connector housing is made from high temperature thermoplastic material rated UL 94 V-0 for excellent flame retardance and glow-wire compliance, ensuring safety and durability in industrial and commercial environments. The right-angle orientation and positive locking feature provide secure and reliable mating with matching receptacles while preventing accidental disconnection.

Its copper alloy contacts are gold plated to maintain superior conductivity and corrosion resistance over extended use. This PCB header includes PCB retention and location features, facilitating precise and stable placement on printed circuit boards during assembly.

Operating voltage rating is 600 V, with a temperature range from -40°C up to 120°C, making it suitable for a wide variety of electronic, industrial control, power distribution, and automation applications. The wire-to-board connector system uses through-hole mount technology with solder termination ensuring solid mechanical and electrical connection.

This series is designed for industries such as electronics manufacturing, industrial machinery, power supplies, HVAC control systems, and testing equipment. For matching UL 94 V-0 rated Mega-Fit receptacles, part numbers 797-5885 or 797-5891 are recommended.

Designed for high current density applications at 23 A per circuit. Features a positive locking mechanism with an audible click when mated. Constructed with high temperature thermoplastic housing with UL 94 V-0 flammability rating.

Includes PCB retention and location features for secure mounting. Male contacts made from copper alloy with gold plating ensure reliable conductivity. Right angle orientation with shrouded design for protection and durability.

Operating voltage up to 600 V and temperature range from -40°C to 120°C allow versatile use. Wire-to-board connector system with through-hole mount suitable for PCB assembly. Termination type is solder, ensuring stable electrical connections.
