DiodesZetex 20 V 400 mA SOT-23 Schottky Diode 3-Pin SDM40E20LS-7-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 20 V 400 mA SOT-23 Schottky Diode 3-Pin SDM40E20LS-7-F

Name: DiodesZetex 20 V 400 mA SOT-23 Schottky Diode 3-Pin SDM40E20LS-7-F
Brand: DiodesZetex
SKU: 363682
Price: 0.23 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.1mm
Length	3mm
Model	SDM40E20LS-7-F
Width	1.4mm
Mount Type	Surface
Series	SDM40E20LS
Maximum Operating Temperature	125°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Standards/Approvals	FBI
Pin Count	3
Automotive Standard	AEC
Maximum Continuous Forward Current If	400mA
Peak Reverse Repetitive Voltage Vrrm	20V
Diode Configuration	Series
Rectifier Type	Schottky
Peak Reverse Current Ir	250μA
Peak Non-Repetitive Forward Surge Current Ifsm	2A
Maximum Forward Voltage Vf	430mV

Key Features

The diode features a Surface Mount package with SOT-23 type for compact PCB integration.
It supports a maximum continuous forward current of 400 mA and a peak non-repetitive forward surge current of 2 A.
Its peak reverse repetitive voltage rating is 20 V providing reliable blocking capability.
The maximum forward voltage drop is 430 mV, supporting low power loss and high efficiency.
Operating temperature range extends from -65°C to 125°C, suitable for automotive and industrial applications.
The package dimensions are compact with a length of 3 mm, width of 1.4 mm, and height of 1.1 mm.
This Schottky diode employs series diode configuration and offers a peak reverse current of 250 μA.
Manufactured to FBI standards and compliant with automotive AEC requirements.

Product Description

DiodesZetex SDM40E20LS-7-F is a high-performance Schottky barrier diode optimized for low forward voltage and high efficiency within a small SOT-23 package.

Featuring a maximum continuous forward current rating of 400 mA and a peak reverse voltage of 20 V, it is ideal for use in power rectification and switching applications across industrial, automotive, and consumer electronics sectors.

The diode operates reliably from -65°C up to 125°C, making it suitable for harsh environmental conditions encountered in automotive electronic systems and industrial equipment.

The compact three-pin SOT-23 surface mount package (3 mm x 1.4 mm x 1.1 mm) facilitates space-saving PCB designs. Its low forward voltage drop of 430 mV reduces power dissipation and improves energy efficiency.

Surface mount SOT-23 package ensures easy PCB assembly and compact footprint. Maximum continuous forward current of 400 mA with peak surge currents up to 2 A. Low forward voltage supports efficient power conversion. Wide operating temperature range from -65°C to 125°C ensures versatility.

Automotive AEC and FBI industry standards compliance guarantees quality and reliability.

This Schottky diode finds applications in industrial power supplies, automotive electronics, communication devices, and consumer electronic products requiring fast switching and low voltage drop.

As a member of the Schottky Diodes & Rectifiers category, the SDM40E20LS-7-F combines compact size, reliability, and performance making it a preferred choice for innovative electronic designs.

Browse our comprehensive catalog of DiodesZetex Schottky diodes and related semiconductor components at EnvMart for your industrial and manufacturing needs.

Explore more products in our Schottky Diodes & Rectifiers category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business
