DiodesZetex 30 V 3 A Schottky Diode 2-Pin DO-214AA B330B-13-F
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 2.3mm |
| Length | 4.57mm |
| Model | B330B-13-F |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | B330B |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | FBI |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 20mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 500mV |
Key Features
- Provides maximum continuous forward current of 3 A for reliable performance.
- Has a peak reverse repetitive voltage rating of 30 V to ensure safe operation.
- Features a low maximum forward voltage of 500 mV for efficient conduction.
- Operates reliably across a wide temperature range from -55°C to 150°C.
- Compact dimensions with length 4.57 mm, width 3.94 mm, and height 2.3 mm.
- Schottky diode configuration with 2 pins and single series B330B design.
- Certified to automotive standard AEC-Q101 for high reliability applications.
- Capable of handling peak non-repetitive forward surge current up to 100 A.
Product Description
DiodesZetex B330B-13-F Schottky Diode is a high-performance semiconductor device designed for efficient power rectification. This 30 V, 3 A diode comes in a compact 2-pin DO-214AA surface mount package, making it suitable for space-constrained industrial and electronic applications.
The diode offers excellent electrical characteristics including a maximum forward voltage of 500 mV and can handle continuous forward currents up to 3 A. It is rated for peak reverse repetitive voltages of 30 V and a peak surge current tolerance of 100 A, which ensures durability and reliable operation under transient conditions.
Its operating temperature range from -55°C to 150°C and certification to AEC-Q101 automotive standards make it suitable for harsh environments including automotive electronics, industrial power supplies, and other demanding operations.
With a compact form factor of 4.57 mm length, 3.94 mm width, and 2.3 mm height, the diode integrates easily into compact PCBs and high-density electronic designs. The single series B330B design features a Schottky barrier that lowers the forward voltage drop and improves efficiency.
Maximum continuous forward current: 3 A. Peak reverse repetitive voltage: 30 V. Maximum forward voltage: 500 mV. Peak non-repetitive forward surge current: 100 A. Operating temperature range: -55°C to 150°C. Package type: DO-214AA surface mount.
Automotive grade: conforms to AEC-Q101 standards. Compact dimensions: 4.57 mm x 3.94 mm x 2.3 mm. Diode configuration: single with 2 pins. Series: B330B Schottky rectifier.
This Schottky diode is commonly used in power supplies, voltage clamping, and reverse polarity protection in industrial, automotive, and consumer electronics sectors. Its thermal stability and reliability make it a preferred choice for designers requiring efficient and robust diode solutions.
Browse the Electronics & Electricals category at EnvMart for similar semiconductor components including other Schottky diodes and rectifiers.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 3 A.
It has a peak reverse repetitive voltage rating of 30 V.
The maximum forward voltage for this model is 500 mV.
This diode operates reliably across a wide temperature range from -55°C to 150°C.
The dimensions of this diode are 4.57 mm in length, 3.94 mm in width, and 2.3 mm in height.
It comes in a DO-214AA surface mount package type.
The diode can handle a peak non-repetitive forward surge current of up to 100 A.
This model is certified to the AEC-Q101 automotive standard for high reliability applications.
This diode has a 2-pin configuration.
The rectifier type of this diode is Schottky.
The peak reverse current for this diode is 20 mA.
The B330B-13-F diode is manufactured in India.
