Hirose DF3 Series Right Angle Through Hole PCB Header 3 Contact 2 mm Pitch 1 Row Shrouded DF3A-3P-2DS

Hirose DF3A-3P-2DS PCB Header is a high-quality right angle through hole pin header connector designed with 3 contacts spaced at a 2 mm pitch in a single row configuration. Featuring a durable polyamide housing, this connector is shrouded to provide protection for the contacts and ensure reliable mating in electronic assemblies.

The connector system supports both board-to-board and wire-to-board connections, making it versatile for various industrial and commercial electronic applications. The copper alloy contacts plated with tin provide excellent electrical conductivity and corrosion resistance.

This PCB header is rated for a current of up to 3 amperes and can withstand voltages up to 250 volts. It is designed with a male contact gender and employs a solder termination type suited for through hole mounting on PCBs. The row pitch is 2 mm ensuring compact and precise layout designs.

Operating effectively in temperature ranges from -30°C to 85°C, this connector meets demanding environmental conditions often encountered in industrial, manufacturing, automation, and electronic instrumentation applications. The product is manufactured in Japan, assuring quality and reliability.

Key features include the shrouded construction for enhanced connection security, polyamide housing material for mechanical strength, and versatile compatibility in connector systems aimed at power and signal transmissions.

Shrouded design for secure and protected contacts. Polyamide housing providing durability and insulation. Copper alloy contacts with tin plating for conductivity and corrosion resistance. Right angle orientation for PCB space optimization.

Through hole mount type for robust mechanical connection. Male contact gender compatible with female headers. Solder termination type for reliable electrical connection. Current rating of 3 amperes and voltage rating of 250 volts.

Operating temperature range from -30°C to 85°C. Designed for board-to-board and wire-to-board systems.

This Hirose DF3 series connector is ideal for use in electronic components, power connectors, industrial equipment, and any applications requiring a high-quality, reliable PCB header.
