Taiwan Semiconductor 45 V 25 A Schottky Diode Through Hole 3-Pin TO-220AB MBR2545CT C0
Specifications
| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 8.24mm |
| Length | 10.5mm |
| Model | MBR2545CT C0 |
| Width | 4.7mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-220AB |
| Minimum Operating Temperature | -65°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 688-2013 Brand: [Taiwan Semiconductor](https://in.rsdelivers.com/brands/taiwan-semiconductor)Manufacturers Part No.: MBR2545CT C0 |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 25A |
| Peak Reverse Repetitive Voltage Vrrm | 45V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200A |
| Maximum Forward Voltage Vf | 1.02V |
| Taiwan Semiconductor 45 V 25 A Diode Schottky 3-Pin TO-220ABRS Stock No. | 688-2013Brand: Taiwan SemiconductorManufacturers Part No.: MBR2545CT C0 |
Key Features
- The diode features a through hole mount type with a 3-pin TO-220AB package.
- It exhibits a peak reverse current of 1 microampere for reliable performance.
- Maximum forward voltage drop is 1.02 V, ensuring low power dissipation.
- Operating temperature ranges from -65°C to 150°C to suit harsh environments.
- Designed with a common cathode diode configuration for efficient rectification.
- The diode supports a peak non-repetitive forward surge current of 200 A.
- Meets automotive standard AEC-Q101 for quality assurance.
Product Description
Taiwan Semiconductor MBR2545CT C0 is a Schottky diode designed for applications requiring a maximum continuous forward current of 25 A and a peak reverse repetitive voltage of 45 V. It is housed in a through hole 3-pin TO-220AB package, suitable for mounting on a PCB.
This diode offers low forward voltage drop of 1.02 V, minimizing power losses in rectification circuits. The device supports a peak non-repetitive forward surge current of 200 A, providing robustness against surge events.
Operating across a wide temperature range from -65°C to 150°C, the diode performs reliably in industrial, automotive, and power management applications. The common cathode diode configuration ensures efficient current flow with minimal losses.
Physical dimensions are compact at 10.5 mm length, 4.7 mm width, and 8.24 mm height, allowing versatile use in circuit designs where space is constrained. Compliance with AEC-Q101 automotive standards underscores its suitability for automotive electronics.
This diode is ideal for use in power supplies, DC-DC converters, and other electronic devices requiring efficient, high-current rectification with minimal voltage drop. Its through hole mounting eases installation in prototype and production environments.
The diode features a through hole mount type with a 3-pin TO-220AB package. It exhibits a peak reverse current of 1 microampere for reliable performance. Maximum forward voltage drop is 1.02 V, ensuring low power dissipation.
Operating temperature ranges from -65°C to 150°C to suit harsh environments. Designed with a common cathode diode configuration for efficient rectification. The diode supports a peak non-repetitive forward surge current of 200 A.
Compact dimensions: length 10.5 mm, width 4.7 mm, and height 8.24 mm. Meets automotive standard AEC-Q101 for quality assurance.
Available in industrial and automotive-grade quality, this diode supports robust and efficient power management. EnvMart offers this Taiwan Semiconductor MBR2545CT C0 Schottky diode for precise and reliable electronic applications.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current is 25 A.
This model features a common cathode diode configuration.
The dimensions are 10.5 mm in length, 4.7 mm in width, and 8.24 mm in height.
The maximum forward voltage drop is 1.02 V.
The operating temperature ranges from -65°C to 150°C.
It supports a peak non-repetitive forward surge current of 200 A.
This diode uses a through hole mount type.
It meets the automotive standard AEC-Q101.
This model has a pin count of 3.
