Taiwan Semiconductor 100 V 60 A Schottky Barrier Diode TO-3P Package MBR60100PT
Specifications
| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 21.3mm |
| Length | 16.4mm |
| Model | MBR60100PT |
| Width | 5.16mm |
| Mount Type | Through Hole |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-3P |
| Minimum Operating Temperature | -65°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 688-2069Brand: Taiwan SemiconductorManufacturers Part No.: MBR60100PT |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 60A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 500A |
| Maximum Forward Voltage Vf | 0.98V |
Key Features
- Through-hole mount type for easy PCB integration.
- Low forward voltage drop of 0.98 V to improve efficiency.
- Common cathode diode configuration provides straightforward circuit design.
- High peak non-repetitive forward surge current of 500 A for robust transient handling.
- Operates reliably between -65°C and 150°C temperature range.
- Automotive grade compliance with AEC-Q101 standard.
- Ideal for power management and rectification applications.
- Designed for industrial, automotive, and power electronics use cases.
Product Description
Taiwan Semiconductor MBR60100PT is a 100 V, 60 A Schottky barrier diode in a TO-3P through-hole package, designed for efficient power rectification and low power loss.
This diode features a low forward voltage drop of 0.98 V, which minimizes conduction losses and improves overall circuit efficiency. The common cathode configuration and 3-pin setup make it suitable for a variety of industrial electronics and automotive applications requiring robust power management components.
Its high peak non-repetitive forward surge current of 500 A ensures durable performance during transient conditions. The device operates over a wide temperature range from -65°C to 150°C, making it ideal for harsh environments.
Compact dimensions of length 16.4 mm, width 5.16 mm, and height 21.3 mm allow for easy integration into power circuits. The diode meets the automotive standard AEC-Q101, highlighting its quality and reliability for automotive and industrial sectors.
Through-hole mount type for secure installation on printed circuit boards. Low forward voltage drop of 0.98 V reduces energy loss. Common cathode configuration simplifies circuit design. High peak surge current capability of 500 A.
Wide operating temperature range from -65°C to 150°C. Compact package size TO-3P (16.4 x 5.16 x 21.3 mm). Automotive grade compliant to AEC-Q101. Durable and reliable diode for power electronics and automotive applications.
3-pin connection enhances stability and performance.
This Taiwan Semiconductor Schottky diode MBR60100PT is widely used in industrial power supplies, automotive electronics, renewable energy inverters, and other high-current switching and rectification applications. Its robust design ensures long operational life and reliable performance in demanding environments.
Explore our extensive catalogue for other power semiconductor devices and related electronics components on EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the MBR60100PT is 60 A.
This model has a peak reverse repetitive voltage rating of 100 V.
The forward voltage drop is 0.98 V, which helps to minimize conduction losses.
It operates reliably within a temperature range of -65°C to 150°C.
The diode comes in a TO-3P package type, suitable for through-hole mounting.
The peak non-repetitive forward surge current is rated at 500 A.
It features a common cathode diode configuration, simplifying circuit design.
This diode has a 3-pin connection, enhancing stability and performance.
Yes, it meets the automotive standard AEC-Q101.
The dimensions are 16.4 mm in length, 5.16 mm in width, and 21.3 mm in height.
It is ideal for power management and rectification applications in industrial, automotive, and power electronics.
The country of origin for the MBR60100PT is India.
