Taiwan Semiconductor 200 V 1 A Surface Mount Switching Diode DO-214AC ES1D R2
Specifications
| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 2.3mm |
| Length | 4.6mm |
| Model | ES1D R2 |
| Width | 2.83mm |
| Mount Type | Surface |
| Series | ES1D |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 950mV |
| Peak Reverse Recovery Time trr | 35ns |
Key Features
- Compact DO-214AC package suitable for surface mount applications.
- Maximum continuous forward current of 1 ampere for reliable switching.
- Peak reverse repetitive voltage rating of 200 volts ensures robust performance.
- Fast peak reverse recovery time of 35 nanoseconds for efficient switching.
- Wide operational temperature range from -55°C to 150°C for versatile environments.
- Low maximum forward voltage of 950 millivolts reduces power loss.
- Capable of handling peak non-repetitive forward surge current up to 30 amperes.
- Single diode configuration with 2 pins designed for power and electronic applications.
Product Description
Taiwan Semiconductor ES1D R2 is a surface mount switching diode packaged in the DO-214AC form factor. It is designed for efficient switching applications requiring a maximum continuous forward current of 1 amp and a peak reverse repetitive voltage of 200 volts.
This diode features a single configuration with two pins and exhibits a fast switching speed characterized by a peak reverse recovery time of 35 nanoseconds, enabling usage in power management and electronic circuit designs.
The ES1D R2 diode operates reliably within a broad temperature range from -55°C to 150°C, ensuring stable performance under varied industrial conditions. Its low maximum forward voltage of 950 millivolts helps minimize power dissipation during operation.
The compact physical dimensions (4.6 mm length, 2.83 mm width, and 2.3 mm height) allow for space-saving layouts on PCBs, especially suitable in discrete semiconductor assemblies and power electronics.
This product does not carry any automotive certification or special industry standards approvals but meets general semiconductor diode functional requirements. Compact DO-214AC surface mount package. Maximum continuous forward current is 1A.
Rated for 200 V peak reverse repetitive voltage. Fast switching with a 35 ns peak reverse recovery time. Operating temperature range from -55°C to 150°C. Maximum forward voltage of 950 mV. Can handle 30 A peak non-repetitive forward surge current.
Small size ideal for PCB mounting. Single diode configuration with 2 pins. Suitable for power and electronic semiconductor applications.
This Taiwan Semiconductor diode is ideal for discrete semiconductor use in electronic components, power conversion, and switching circuits. The product is featured in our semiconductor category and is recommended for industrial, manufacturing, and electronics design applications. Browse related switching diodes and semiconductor components on EnvMart for complete solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
