Vishay 1-Element Bi-Directional TVS Diode 1500 W, 2-Pin, Through Hole Mount 1.5KE8.2CA-E3/54

Vishay 1.5KE8.2CA-E3/54 is a high-performance 1-element bi-directional transient voltage suppression (TVS) diode designed for effective protection against voltage transients and surges in electronic circuits. This 2-pin diode package uses a through-hole mount style for straightforward integration in PCB designs.

With a minimum breakdown voltage of 7.79 V and a peak pulse power dissipation rating of 1500 W, the device safeguards sensitive electronic components from damage caused by transient voltage spikes. Its bi-directional configuration allows it to handle surges in both AC and DC lines, making it versatile for various power and signal line protection applications.

The diode provides a clamping voltage of 12.1 V and a maximum peak pulse current of 124 A, ensuring prompt suppression of transient events without compromising circuit functionality. It operates reliably within an extensive temperature range of -55°C to 175°C, supporting use in harsh environments including industrial and automotive sectors.

This TVS diode complies with AEC-Q101 automotive standards, offering excellent durability for automotive electronics. Its compact axial package features 9.5 mm length and 5.3 mm diameter, allowing efficient PCB space utilization. Electrostatic discharge (ESD) protection enhances the device's resilience against electrostatic events.

Single diode configuration ensuring reliable surge protection. Bi-directional type suitable for AC and DC transient suppression. Minimum breakdown voltage of 7.79 V stabilizes sensitive electronics. 1500 W peak pulse power dissipation for robust protection.

Clamping voltage of 12.1 V efficiently clamps transient surges. Wide operating temperature range from -55°C to 175°C. Compliant with AEC-Q101 automotive quality standard. Compact through hole 2-pin axial package measuring 9.5 mm length.

ESD protection reduces damage from electrostatic discharge.

This product is ideally suited for industrial electronics, automotive electronics, power supplies, telecommunication equipment, and other applications requiring transient voltage suppression and surge protection. Vishay TVS diodes are well-regarded for their robustness and reliability in harsh operating conditions.

Explore the category of TVS Diodes and other Vishay electronic components at EnvMart for comprehensive solutions in transient protection.
