Vishay 1-Element Uni-Directional Transient Voltage Suppressor 1500 W 2-Pin DO-214AB SMCJ100A-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ100A-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | SMCJ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AB (SMC) |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | AEC-Q101, RoHS, UL 94 V-0 |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 162V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 111V |
| Maximum Reverse Stand-off Voltage Vwm | 100V |
| Peak Pulse Power Dissipation Pppm | 1500W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 9.3A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Uni-directional configuration protects sensitive electronic circuits against voltage transients.
- Surface-mount design enables automated PCB assembly and efficient space utilization.
- Peak pulse power dissipation of 1500 W ensures high transient protection capacity.
- Operating temperature range spans from -55°C to 150°C for reliable performance in harsh environments.
- Compliant with automotive standard AEC-Q101 and RoHS for quality and environmental safety.
- Low maximum reverse leakage current of 1μA reduces standby power consumption.
- Clamping voltage of 162 V limits voltage spikes effectively during transient events.
- Test current of 1mA and maximum peak pulse current of 9.3A ensures precise and robust protection.
Product Description
Vishay SMCJ100A-E3/57T is a high-performance Uni-Directional Transient Voltage Suppressor designed for protecting electronic circuits against damaging voltage spikes. This device features a single element diode configuration optimized for uni-directional protection, delivering 1500 W peak pulse power dissipation.
Encapsulated in the DO-214AB (SMC) surface-mount package, it provides compact size with dimensions of 7.11 mm length, 6.22 mm width, and 2.42 mm height, ideal for high-density PCB layouts.
Operating reliably in temperatures ranging from -55°C to 150°C, this transient voltage suppressor meets automotive AEC-Q101 and environmental RoHS standards, making it suitable for automotive, industrial, and consumer electronics applications demanding robust transient protection.
The device characteristics include a minimum breakdown voltage of 111 V, maximum reverse stand-off voltage of 100 V, a clamping voltage at 162 V, and a maximum peak pulse current rating of 9.3 A. Its low maximum reverse leakage current of 1 μA ensures minimal leakage during normal operation.
Designed to protect sensitive circuits from ESD events, the Vishay SMCJ100A-E3/57T is an essential component for safeguarding power supplies, communication equipment, and automotive electronics against transient overvoltage conditions.
Uni-directional transient voltage suppression for voltage spike protection. High peak pulse power of 1500 W in compact DO-214AB package. Wide temperature range ensures stable performance in harsh environments. Meets automotive AEC-Q101 and RoHS compliance standards.
Low leakage current for energy efficient operation. Compact design suitable for automated PCB assembly and space-constrained systems. High clamping voltage rating protects sensitive components effectively. Single element chip ensuring precise transient suppression.
These features make the Vishay SMCJ100A-E3/57T ideal for industrial control, automotive electronics, telecommunication equipment, and power supply protection applications. Explore more high-quality TVS Diodes and semiconductor components in the Electronics & Electricals category on EnvMart for optimized circuit protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is 1500 W, providing robust transient protection.
The clamping voltage is 162 V, which effectively limits voltage spikes during transient events.
The dimensions of the SMCJ100A-E3/57T are 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
It complies with the automotive standard AEC-Q101, ensuring quality for automotive applications.
This model features a single element diode configuration, optimized for uni-directional protection.
The maximum peak pulse current rating is 9.3 A, providing effective transient suppression.
It utilizes a surface mount design, making it suitable for automated PCB assembly.
The minimum breakdown voltage is 111 V, which is critical for effective voltage spike protection.
This model is suitable for applications in automotive electronics, industrial control, and telecommunication equipment.
It meets RoHS and UL 94 V-0 standards, ensuring compliance with environmental and safety regulations.
