Taiwan Semiconductor 1-Element Uni-Directional Transient Voltage Suppressor 600W DO-15 P6KE300A

Taiwan Semiconductor P6KE300A is a 1-element uni-directional transient voltage suppressor designed to protect sensitive electronic components from voltage spikes and transients. It features a 600 watt peak pulse power dissipation capability ensuring reliable defense against surge voltages in various industrial and commercial electronic circuits. The device is housed in a DO-15 package with through-hole mounting, facilitating straightforward PCB implementation in discrete semiconductor applications.

With a minimum breakdown voltage of 285 V and a maximum reverse standoff voltage of 256 V, this transient voltage suppressor efficiently clamps transient spikes up to a clamping voltage of 414 V. The component supports a maximum peak pulse current of 1.5 A, suitable for a wide range of electrical and electronic systems.

Operating over a broad temperature range from -65°C to 175°C, the P6KE300A ensures performance stability under harsh environmental conditions. Its low leakage current of 5 μA contributes to energy-efficient operation, making it ideal for power and signal line protection in industrial control, automotive electronics, telecommunications, and power management circuits.

The compact size with dimensions length 7.62 mm, width and height 3.56 mm, and a diameter of 3.6 mm allows usage in space-constrained designs, while the single element per chip configuration assures effective transient suppression.

This TVS diode complies with standard semiconductor device applications but is not listed with automotive or special certifications. It is commonly used in electronic equipment requiring high surge protection and is suitable for use in PCB assemblies, power supply lines, and signal conditioning circuits.

Uni-directional diode configuration suitable for transient voltage suppression. 600 watt peak pulse power dissipation withstands high energy spikes. Package type DO-15 with through hole mounting for easy PCB integration.

Minimum breakdown voltage of 285 V with maximum reverse standoff voltage of 256 V. Operating temperature range from -65°C to 175°C for robust environmental performance. Maximum peak pulse current of 1.5 A and clamping voltage of 414 V.

Compact dimensions: length 7.62 mm, width and height 3.56 mm diameter 3.6 mm. Low maximum reverse leakage current of 5 μA ensuring efficient operation. Single element per chip design for reliable surge protection.

This transient voltage suppressor is ideal for industrial, telecommunications, automotive electronics, and consumer electronic applications requiring robust protection from voltage surges.
