Vishay 1-Element Bi-Directional TVS Diode 600 W, 2-Pin DO-204AC P6KE12CA-E3/54

Vishay P6KE12CA-E3/54 1-Element Bi-Directional TVS Diode is a transient voltage suppressor designed for protecting sensitive electronic circuits against voltage spikes and transient surges. It delivers a peak pulse power dissipation of 600 W in a durable DO-204AC axial leaded package suitable for through-hole mounting, ensuring reliable circuit protection in both industrial and automotive environments.

This TVS diode features a single element and bi-directional diode configuration, making it ideal for AC or pulse systems where voltage transients occur in both directions. It has a minimum breakdown voltage (Vbr) of 11.4 V and a clamping voltage of 16.7 V to efficiently clamp overvoltages that might otherwise damage connected components.

The diode supports operation over a wide temperature range from -55°C to 175°C, ensuring stable performance under harsh conditions. With a maximum peak pulse current of 35.9 A and a maximum reverse leakage current of 5 μA, it offers robust protection combined with low leakage loss for enhanced energy efficiency.

The axial leaded package dimensions are 7.6 mm in length and 3.6 mm in diameter, which allows a compact design footprint compatible with various PCB layouts. It complies with the automotive standard AEC-Q101, confirming its suitability for automotive applications with high reliability requirements.

This product is manufactured in China, ensuring consistent quality control and supply standards. It is recommended for use in industrial, automotive, and electronic manufacturing applications requiring effective transient voltage suppression and circuit protection.

Single diode configuration designed for bi-directional transient voltage suppression. Minimum breakdown voltage of 11.4 V ensures reliable protection. Features a maximum peak pulse power dissipation of 600 watts. Supports a maximum operating temperature of up to 175°C for demanding applications.

Axial leaded through-hole mount type for easy PCB integration. Clamping voltage of 16.7 V for effective clamping of voltage spikes. Offers excellent ESD protection with an automotive standard AEC-Q101 certification. Compact dimensions with a length of 7.6 mm and diameter of 3.6 mm.

Maximum reverse stand-off voltage of 10.2 V and test current of 1 mA. Manufactured in China with high quality and reliability standards. Explore the Vishay range of TVS Diodes and other semiconductor solutions for comprehensive electronic component needs here at EnvMart.
