TDK Polyester Capacitor (PET) 10 nF 100V AC/DC Through Hole 2 Pins B32529C1103J189

TDK B32529C1103J189 polyester capacitor (PET) is a film capacitor designed for electronic industrial applications requiring stable electrical characteristics. It offers 10 nF capacitance at both 100V AC and DC rated voltages, making it suitable for use in power and signal circuits. The capacitor features a through hole mount with two parallel leads spaced at 5mm pitch, facilitating easy PCB assembly.

Constructed with polyethylene terephthalate dielectric material and stacked-film technology, this component ensures high pulse strength and excellent contact reliability. Its plastic casing and epoxy sealing provide resistance against environmental factors, while lead-free tinned parallel wire terminals adhere to RoHS compliance.

The maximum operating temperature is rated at 110°C, meeting demanding automotive standards such as AEC-Q200 Rev D and UL approvals. With compact dimensions of 7.3mm length, 2.5mm width, and 6.5mm height, it fits well within space-constrained layouts. The 0.5mm lead diameter enhances mechanical robustness.

This capacitor is widely used for blocking, coupling, decoupling, bypassing, and radio frequency interference (RFI) suppression in electronic equipment spanning automotive, industrial, and manufacturing sectors.

Polyester film dielectric for stable electrical properties. Through hole mounting for reliable PCB connection. Compliance with automotive and safety standards. Compact dimensions suited for dense circuit layouts. High mechanical and thermal endurance.

Lead-free and RoHS compliant materials. Ideal for EMI/RFI filtering and signal conditioning. Manufactured in Brazil ensuring quality control. Explore the extensive range of Capacitors and electronic components at EnvMart for industrial and commercial applications.
