Vishay Single Layer Ceramic Capacitor 500 pF 30 kV Y5U Dielectric Screw Terminal 85°C 715C30DKT50

Vishay 715C30DKT50 is a high performance single layer ceramic capacitor engineered for industrial and power electronics applications requiring high voltage tolerance and reliable operation. This capacitor features a 500 pF capacitance with a robust 30 kV DC voltage rating, making it ideal for advanced filtering, surge protection, and isolation tasks in challenging environments.

The Y5U dielectric material provides superior stability across wide temperature ranges, with specified tolerance from -20% to +80% and operational temperatures from -30°C to 85°C. Epoxy coating enhances insulation and mechanical durability while maintaining low inductance and high insulation resistance, ensuring operational integrity under electrical stress.

Screw terminal mount type offers secure, efficient connections for fast installation and maintenance. The capacitor’s physical dimensions (34.5 mm height and 26.7 mm diameter) are optimized for compact layouts on PCBs, enclosures, or rack assemblies. The Series 715C design is compliant with IEC 61249-2-21, EC, and RoHS safety and environmental standards.

Key features include a dissipation factor of only 0.02%, suppression class II rating for noise reduction and transient protection, and compatibility with industrial, laboratory, and medical equipment such as high voltage power supplies, x-ray imaging devices, welding equipment, and scientific instruments.

Thanks to its high voltage capacity and reliable screw terminal interface, Vishay 715C30DKT50 supports demanding use cases in commercial and industrial electrical systems, enhancing circuit performance and system reliability. Country of origin is Germany, ensuring precision engineering and manufacturing quality.

Single layer ceramic construction with epoxy coating. Capacitance rated at 500 pF for precise filtering applications. High voltage performance up to 30 kV DC. Y5U dielectric ensures wide temperature tolerance and electrical stability.

Screw terminal mounting simplifies secure connections. Operates reliably in temperatures from -30°C to 85°C. Low inductance and high insulation resistance ideal for demanding environments. Complies with IEC 61249-2-21, EC, and RoHS standards.

Suitable for industrial power supplies, x-ray equipment, and welding machinery. Explore more Vishay high voltage Capacitors and industrial passive components in the EnvMart Electronics Components category.
