Vishay Standard Recovery Diode 1600 V 320 A 3-Pin MAGN-A-PAK VS-VSKD320-16PBF
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 5.5mm |
| Brand | Vishay |
| Height | 52mm |
| Length | 115mm |
| Model | VS-VSKD320-16PBF |
| Width | 50mm |
| Mount Type | Panel |
| Series | VS-VSK |
| Maximum Operating Temperature | 150°C |
| Package Type | MAGN-A-PAK |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | UL Approved File E78996 |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 320A |
| Peak Reverse Repetitive Voltage Vrrm | 1600V |
| Diode Configuration | Series |
| Rectifier Type | Recovery |
| Peak Reverse Current Ir | 50mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 10.6kA |
| Maximum Forward Voltage Vf | 1.28V |
| IXYS 1600 V 270 A Diode General Purpose 3-Pin Y1-CU MDD255-16N1Brand | IXYS |
Key Features
- Standard recovery power diode in industry-standard MAGN-A-PAK package.
- Designed for panel mounting with three pins for secure connection.
- Maximum forward voltage of 1.28 V ensuring efficient conduction.
- Supports peak non-repetitive forward surge current up to 10.6 kA.
- Operates reliably from -40°C up to 150°C operating temperature range.
- 3-pin series diode configuration designed for power rectification applications.
- UL approved with file number E78996 for quality assurance.
Product Description
Vishay VS-VSKD320-16PBF standard recovery diode is a high-efficiency power diode designed for industrial and electronic applications requiring robust rectification capabilities with high current and voltage ratings. This diode is housed in a durable MAGN-A-PAK panel mount package featuring a 3-pin configuration, providing reliable and secure electrical connections suitable for various power supply and conversion systems.
The diode supports a maximum continuous forward current of 320 A and a peak reverse repetitive voltage (Vrrm) of 1600 V, making it suitable for demanding power electronics environments. Its standard recovery characteristic ensures controlled switching performance in rectifier applications.
Key electrical parameters include a maximum forward voltage of 1.28 V and a peak non-repetitive surge current rating of 10.6 kA, allowing the diode to handle short surge conditions effectively. The diode operates within a wide temperature range from -40°C to 150°C, supporting reliable performance in harsh industrial conditions.
Physically, the diode measures 115 mm in length, 52 mm in height, 50 mm in width, with pin diameters of 5.5 mm, enabling straightforward mounting and integration into power systems. Compliance with UL standards (File E78996) ensures adherence to safety and quality norms.
Standard recovery power diode with high current and voltage ratings. Industry-standard MAGN-A-PAK panel mount package for secure fixed installation. Robust electrical characteristics for industrial power rectification tasks.
Wide operating temperature range up to 150°C for harsh environments. High surge current capacity to handle transient overloads safely. UL approved for assured product quality and safety compliance. Dimensions and pin configuration designed for ease of installation.
This Vishay diode is ideal for use in industrial power supply systems, motor drives, welding equipment, and other heavy-duty electrical applications requiring durable standard recovery rectifiers. Explore more high-quality power semiconductors and components in the Electronics & Electricals category at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this diode is 320 A.
The maximum forward voltage is 1.28 V.
It supports a peak non-repetitive forward surge current of up to 10.6 kA.
The operating temperature range is from -40°C to 150°C.
This diode is designed for panel mounting.
The diode measures 115 mm in length, 52 mm in height, and 50 mm in width.
It has a 3-pin configuration.
Yes, it is UL approved with file number E78996.
The diode configuration is series.
This diode is suitable for industrial power supply systems, motor drives, welding equipment, and other heavy-duty electrical applications.
