Infineon IPA N-Channel MOSFET, 11 A, 40 V, Surface Mount TO-263 Package, 7-Pin IRL40SC209
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Model | IRL40SC209 |
| Mount Type | Surface |
| Series | IPA |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-263 |
| Minimum Operating Temperature | -55°C |
| Typical Applications | DC motors, battery management systems,inverters, and DC-DC converters |
| Standards/Approvals | RoHS |
| Pin Count | 7 |
| Automotive Standard | AEC-Q101 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 11A |
| Maximum Drain Source Voltage Vds | 40V |
| Maximum Drain Source Resistance Rds | 2.9mΩ |
| Maximum Power Dissipation Pd | 81W |
| Typical Gate Charge Qg @ Vgs | 80nC |
| Maximum Gate Source Voltage Vgs | 20V |
| Forward Voltage Vf | 1.2V |
Key Features
- Designed with a maximum power dissipation of 81 W for reliable thermal performance.
- Features a low drain-source resistance of 2.9 milliohms for high efficiency switching.
- Operates within a wide temperature range from -55°C to 175°C.
- Equipped with automotive standard AEC-Q101 qualification ensuring robustness.
- Maximum gate-source voltage rating of 20 V supports versatile control applications.
- Typical gate charge of 80 nC facilitates fast switching performance.
- Forward voltage drop of 1.2 V under typical conditions reduces conduction loss.
- Ideal for applications including DC motors, battery management systems, inverters, and DC-DC converters.
Product Description
The Infineon IRL40SC209 IPA series N-Channel MOSFET is designed for surface mount technology using the TO-263 package with 7 pins, providing efficient power management in compact electronic circuits.
With a continuous drain current rating of up to 11 A and a maximum drain-source voltage of 40 V, this MOSFET supports robust operation in high-performance power switching applications while maintaining low on-resistance for minimal power loss.
The device handles power dissipation up to 81 watts and operates reliably in a broad temperature range from -55°C to 175°C, making it suitable for harsh industrial and automotive environments, as it complies with the AEC-Q101 automotive standard and RoHS directives.
Key electrical characteristics include a maximum gate-source voltage of 20 V, a typical forward voltage of 1.2 V, and a typical gate charge of 80 nC at Vgs, allowing efficient switching and control in DC motors, battery management systems, inverters, and DC-DC converters.
Compact 7-pin TO-263 package for surface mounting. Low drain-source on-resistance of 2.9 milliohms. High power dissipation capability of 81 W. Wide operating temperature range from -55°C to 175°C. Automotive qualified to AEC-Q101 standard.
Maximum gate-source voltage rating of 20 V for flexible control. Typical gate charge of 80 nC supports fast switching. Typical forward voltage of 1.2 V reduces conduction losses. RoHS compliant for environmental safety.
This MOSFET is optimized for industrial, automotive, and consumer electronics applications requiring efficient power control and switching. It supports modern designs found in DC motor drives, battery management, inverters, and step-down DC-DC converters.
Explore more power electronics and semiconductor components on EnvMart to find compatible devices for your projects and industrial needs.
Explore more products in our Power MOSFET category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for this model is 11 A.
This unit has a maximum drain-source voltage rating of 40 V.
It can handle a maximum power dissipation of 81 W.
The typical gate charge is 80 nC at Vgs.
It operates within a wide temperature range from -55°C to 175°C.
This model is packaged in a TO-263 surface mount package with 7 pins.
It is qualified to the AEC-Q101 automotive standard.
The maximum gate-source voltage rating is 20 V.
The typical forward voltage drop is 1.2 V.
It is ideal for applications including DC motors, battery management systems, inverters, and DC-DC converters.
The maximum drain-source resistance is 2.9 milliohms.
Yes, this model is RoHS compliant for environmental safety.
