onsemi PNP Power Transistor TO-247, -16 A Maximum DC Collector Current, -250 V Collector Emitter Voltage MJW21195G

onsemi MJW21195G is a PNP power transistor featuring a TO-247 package suitable for through-hole mounting. It supports a maximum DC collector current of -16 A and a collector emitter voltage rating of -250 V, making it ideal for power electronic and amplification applications.

This transistor is designed for industrial use with a maximum power dissipation rating of 200 W, supporting demanding conditions commonly found in power supplies and motor control circuits. Its maximum operating temperature of 150°C allows it to withstand elevated thermal loads.

With a minimum DC current gain (hFE) of 8 and a maximum transition frequency of 1 MHz, the MJW21195G is optimized for medium frequency switching applications. The component features a durable TO-247 3-pin configuration, supporting single transistor use cases.

The transistor operates reliably in a temperature range from -65°C to 150°C, and its robust voltage ratings include a maximum collector-base voltage of 400 V dc and a maximum emitter-base voltage of 5 V. Its physical dimensions are precisely 41.91 mm height, 5.3 mm width, and 16.26 mm length, facilitating easy integration into electronic assemblies.

Designed for through-hole mounting using the TO-247 package. Supports maximum power dissipation of 200 watts for robust performance. Features a maximum operating temperature of 150°C for reliable use under harsh conditions.

Has a low DC current gain minimum value of 8, suitable for power switching applications. Equipped with 3 pins, designed for single transistor configuration. Maximum transition frequency of 1 MHz, appropriate for medium frequency applications.

Wide operating temperature range from -65°C to 150°C to accommodate various environments. Dimensions are 41.91 mm in height, 5.3 mm in width, and 16.26 mm in length. Collector-base voltage maximum rated at 400 V dc and emitter-base voltage at 5 V.

This PNP power transistor is ideal for industrial sectors including power electronics manufacturing, HVAC systems, industrial motor controls, and laboratory electronics development. Its rugged design and thermal endurance make it suitable for commercial and industrial electronic component applications.
