Vishay 600 V 435 A Diode Recovery 3-Pin INT-A-PAK VS-VSKDU300/06PBF
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 28mm |
| Length | 94mm |
| Model | VS-VSKDU300/06PBF |
| Width | 35mm |
| Mount Type | Panel |
| Series | VSX |
| Maximum Operating Temperature | 150°C |
| Package Type | INT-A-PAK |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 435A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Series |
| Rectifier Type | Recovery |
| Peak Reverse Current Ir | 50mA |
| Maximum Forward Voltage Vf | 1.96V |
| Peak Reverse Recovery Time trr | 260ns |
Key Features
- The diode features a panel mount type and an INT-A-PAK package.
- It has a maximum continuous forward current rating of 435 amperes.
- The peak reverse repetitive voltage is rated at 600 volts.
- The diode configuration is series with a recovery rectifier type.
- Operates safely in temperature ranges from -40° C to 150° C.
- The peak reverse recovery time is 260 nanoseconds for ultrafast switching.
- The device has a maximum forward voltage of 1.96 volts.
- The diode has a 3-pin connection and peak reverse current of 50 mA.
Product Description
Vishay VS-VSKDU300/06PBF Diode Recovery 3-Pin INT-A-PAK is a reliable semiconductor diode designed for power applications requiring high continuous current and voltage endurance. Rated at 600 V peak reverse repetitive voltage and 435 A maximum continuous forward current, this diode ensures efficient electrical performance in harsh environments.
The device is housed in an INT-A-PAK panel mount package suitable for industrial and electronic assembly lines, providing a compact 3-pin design for easy integration.
It features a recovery rectifier type with a very rapid peak reverse recovery time of 260 nanoseconds, enabling improved switching speeds for power conversion or rectification tasks.
With a maximum forward voltage of 1.96 V and a peak reverse current of 50 mA, the diode delivers high efficiency and low leakage currents. Its operational temperature range from -40° C to 150° C makes it highly durable for various applications.
Physical dimensions of 94 mm length, 35 mm width, and 28 mm height align with typical industry standards for panel-mounted rectifier diodes. The diode is mounted on panels with a rugged INT-A-PAK package design. Rated for ultrafast recovery with a 260 ns peak reverse recovery time.
Capable of handling high continuous current of up to 435 A. Designed to withstand voltages up to 600 V reverse repetitive peak. Operational temperature from -40° C to 150° C ensures reliability across climates. Compact 3-pin configuration for easy installation in assemblies.
Low forward voltage drop at 1.96 V improves power efficiency.
This diode is well-suited for industrial, electronics manufacturing, power rectification, and high-speed switching use cases, contributing to enhanced performance and reliability in electronic components.
Explore our extensive Vishay semiconductor diode category for compatible components and solutions optimized for power electronics and discrete semiconductor applications.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating is 435 amperes.
The peak reverse repetitive voltage is rated at 600 volts.
It operates safely within a temperature range from -40° C to 150° C.
The peak reverse recovery time is 260 nanoseconds, allowing for ultrafast switching.
The diode has a length of 94 mm, a width of 35 mm, and a height of 28 mm.
It is housed in an INT-A-PAK package, suitable for panel mounting.
The maximum forward voltage drop is 1.96 volts.
The peak reverse current is rated at 50 mA.
The diode configuration is series, with a recovery rectifier type.
It is well-suited for industrial, electronics manufacturing, power rectification, and high-speed switching applications.
This diode features a 3-pin connection.
The country of origin for this diode is India.
