Vishay 60 V 20 A Rectifier & Schottky Diode Schottky 3-Pin DPAK V20PW60HM3/I

Name: Vishay 60 V 20 A Rectifier & Schottky Diode Schottky 3-Pin DPAK V20PW60HM3/I
Brand: Vishay
SKU: 309329
Price: 89.84 INR
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Vishay Condition New

Specifications

Country of Origin	India
Diameter	13in
Brand	Vishay
Height	1.3mm
Length	6.1mm
Model	V20PW60HM3/I
Width	5.97mm
Mount Type	Surface
Series	eSMP
Maximum Operating Temperature	150°C
Package Type	TO-252
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	20A
Peak Reverse Repetitive Voltage Vrrm	60V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	70mA
Peak Non-Repetitive Forward Surge Current Ifsm	200A
Maximum Forward Voltage Vf	0.66V

Key Features

The diode features trench MOS Schottky technology ensuring a low forward voltage drop.
It operates efficiently with low power losses suitable for high-frequency DC/DC converters.
Mount type is surface mount with a TO-252 package for easy PCB integration.
Rated for operation from -40°C to 150°C for reliability under various conditions.
Peak non-repetitive forward surge current is 200 A for transient protection.
The component is AEC-Q101 automotive standard qualified, suitable for automotive electronics.
RoHS compliant, ensuring environmental safety and regulatory compliance.
Pin count is 3, designed for typical rectifier diode circuitry applications.

Product Description

Vishay V20PW60HM3/I Rectifier & Schottky Diode is a high-current density surface-mount device using trench MOS Schottky technology for very low forward voltage drop and high efficiency. Its 3-pin DPAK TO-252 package features a low profile height of 1.3 mm, allowing for compact PCB layouts and automated placement. The diode supports a maximum continuous forward current of 20 A and a peak reverse repetitive voltage of 60 V, making it ideal for polarity protection, freewheeling diodes, and low-voltage high-frequency DC/DC converters.

Its robust design includes an operating temperature range from -40°C up to 150°C, robust surge capability with a 200 A peak non-repetitive forward surge current rating, and compliance with AEC-Q101 automotive standards. The diode’s minimized power losses and RoHS compliance make it well-suited for industrial, automotive, and electronic component manufacturing environments.

The compact form factor with dimensions 6.1 mm length, 5.97 mm width, and 1.3 mm height ensures space efficiency in electronic assembly. The device’s low peak reverse current of 70 mA contributes to its efficiency in various semiconductor applications.

The diode incorporates trench MOS Schottky technology for low forward voltage drop. Low profile 3-pin DPAK TO-252 packaging supports automated placement. Rated maximum continuous forward current of 20 A. Peak reverse repetitive voltage of 60 V ensures reliability in blocking reverse current.

Wide operating temperature range from -40°C to 150°C for durability. Peak non-repetitive forward surge current rating of 200 A for transient robustness. AEC-Q101 qualification makes it suitable for automotive electronics.

RoHS compliant for environmental and safety standards adherence. Compact dimensions support space-saving PCB designs. Minimal peak reverse current of 70 mA reduces energy losses.

This Vishay rectifier and Schottky diode is ideal for applications in industrial electronics, automotive systems, power converters, and manufacturing equipment requiring efficient, compact, and reliable diode solutions. Explore more products in the Schottky Diodes & Rectifiers category on EnvMart.
