Toshiba 1 2-Input AND Logic Gate CMOS Surface Mount IC 5-Pin SOT-353 TC7SH08FU,LJ(CT)

Toshiba TC7SH08FU,LJ(CT) is a 1 2-input AND logic gate CMOS integrated circuit designed for surface mounting in a compact 5-pin SOT-353 package. It belongs to Toshiba's L-MOS very high-speed logic device family, featuring low power consumption and high noise immunity.

Operating over a voltage range of 2 to 5.5 volts DC, this IC ensures reliable digital logic operation with a typical propagation delay of 10 nanoseconds. It performs effectively in operating temperature conditions from -40°C up to 125°C, making it appropriate for automotive and industrial applications where temperature resilience is critical.

This CMOS logic gate IC provides digital output with a maximum high level current of -8 mA and maximum low level output current of 8 mA, supporting robust signal driving capabilities. The device does not incorporate a Schmitt Trigger input and has one element with two inputs per gate.

Its small footprint SOT-353 package aids space-saving PCB layouts in electronic designs. Toshiba's semiconductor manufacturing quality standards ensure consistent device performance and longevity, with manufacturing origin from Japan.

Operates on a wide supply voltage range between 2V and 5.5V DC. High-speed logic performance with propagation delay as low as 10ns. Wide temperature operating range from -40°C to 125°C. Compliant with automotive standard AEC-Q100 for enhanced reliability.

Utilizes CMOS technology for low power dissipation and high noise immunity. Surface mount package SOT-353 with 5 pin count facilitates compact PCB assembly. Digital output suitable for various industrial and automotive electronic applications.

This detailed IC is ideal for use in industrial automation, automotive electronics, and general-purpose digital logic circuits where compact size, speed, and reliability are required. Explore more semiconductor components and Logic ICs within EnvMart's extensive product catalog for complementary or alternative solutions.
