DiodesZetex 4 2-Input NAND Schmitt Trigger Input Logic Gate 14-Pin TSSOP 74HC00T14-13

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 4 2-Input NAND Schmitt Trigger Input Logic Gate 14-Pin TSSOP 74HC00T14-13

Name: DiodesZetex 4 2-Input NAND Schmitt Trigger Input Logic Gate 14-Pin TSSOP 74HC00T14-13
Brand: DiodesZetex
SKU: 409975
Price: 0.17 USD
Availability: InStock



Category Logic IC Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.05mm
Length	5.1mm
Model	74HC00T14-13
Mount Type	Surface
Output type	Push Pull
Supply Voltage range	2 V to 6 V
Input Type	Schmitt Trigger
Maximum Operating Temperature	125°C
Package Type	TSSOP
Minimum Operating Temperature	-40°C
Pin Count	14
Number of Elements	4
Maximum Supply Voltage	6V
Logic Family	HC
Logic Function	NAND
Minimum Supply Voltage	2V
Maximum High Level Output Current	-4mA
Maximum Propagation Delay Time @ CL	23ns
Maximum Low Level Output Current	5.2mA
Number of Inputs per Gate	2
Sinks or Sources 4 mA at VCC	4.5 V

Key Features

The IC contains 4 NAND gates, each with 2 Schmitt trigger inputs for noise immunity.
Packaged in a 14-pin TSSOP surface mount type suitable for compact PCB designs.
Operates at a supply voltage range of 2 V to 6 V ensuring wide operability.
Propagation delay time of 23 ns at CL provides fast switching for digital circuits.
Operational temperature range from -40°C to 125°C supports harsh environments.
Output type is Push-Pull with output current ratings of -4 mA (high) and 5.2 mA (low).
This component is ideal for industrial and electronic applications requiring Schmitt trigger NAND logic functionality.

Product Description

DiodesZetex 74HC00T14-13 is a high-speed 4 2-input NAND Schmitt trigger input logic gate IC fabricated using CMOS technology, ensuring low power consumption and reliable operation.

This logic IC is housed in a compact 14-pin TSSOP surface mount package, making it suitable for modern PCB layouts with space constraints. Designed to operate across a supply voltage range of 2 V to 6 V, it can be integrated into various electronic systems easily.

The NAND gates include Schmitt trigger inputs which enhance noise immunity and signal integrity in noisy industrial and commercial environments. With a maximum propagation delay of 23 ns at load capacitance, this IC offers fast operational speed essential for timing-critical applications.

Its operating temperature range of -40°C to 125°C allows deployment in demanding temperature conditions encountered in industrial and automotive electronics. The IC contains 4 NAND logic gates each having 2 inputs with Schmitt trigger functionality.

Packaged as a 14-pin TSSOP surface mount device suitable for automated assembly. Operating voltage flexibility from 2 V to 6 V supports various digital system voltages. Reliable push-pull output stage delivering output currents up to ±5.2 mA.

Fully RoHS compliant with no automotive standard classification. This DiodesZetex logic gate IC is commonly used in electronic equipment, embedded system designs, communication devices, and industrial control circuits. Its noise-immunity and quick switching characteristics make it ideal for applications in semiconductor logic functions requiring stable and efficient NAND gate logic.
