Vishay 45 V 6 A Schottky Barrier Schottky Diode Surface Mount TO-252 Package V6PWL45HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PWL45HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 45V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.38V |
Key Features
- Maximum continuous forward current of 6 A for reliable operation.
- Peak repetitive reverse voltage rated at 45 V for robust voltage handling.
- Low forward voltage drop of 0.38 V reducing power losses.
- Surface mount package type TO-252 enabling automated PCB assembly.
- Operating temperature range from -40°C to 175°C for harsh environments.
- High surge current capability with 100 A non-repetitive forward surge current.
- Constructed with trench MOS barrier Schottky technology for efficient performance.
- Compliant with RoHS and automotive standard AEC-Q101 for automotive and industrial use.
Product Description
Vishay V6PWL45HM3/I is a high current density Schottky barrier diode designed for surface mount applications with a TO-252 package. It supports a maximum continuous forward current of 6 A and can withstand a peak repetitive reverse voltage of 45 V, making it suitable for various power electronic circuits.
The diode features trench MOS barrier Schottky technology, which ensures low forward voltage drop of 0.38 V and high efficiency by minimizing power losses. It is optimized for automated placement with a very low profile design, having a typical height of only 1.3 mm.
Operating reliably over a wide temperature range from -40°C to 175°C, it is ideal for demanding industrial environments and applications including DC/DC converters, polarity protection, and freewheeling diodes in power supplies.
The V6PWL45HM3/I meets stringent quality standards such as RoHS compliance and the automotive industry standard AEC-Q101, ensuring suitability for automotive and other high-reliability sectors. It also supports a high surge current of 100 A, providing robustness under transient load conditions.
Maximum continuous forward current of 6 A. Peak reverse voltage rating of 45 V. Low forward voltage drop of 0.38 V decreases power loss. Surface mount TO-252 package eases PCB assembly. Wide operating temperature: -40°C to 175°C.
High surge current capacity of 100 A. Trench MOS Barrier Schottky technology for efficiency. RoHS compliant and meets AEC-Q101 automotive standard. Low profile design with 1.3 mm height. Suitable for DC/DC converters, polarity protection, and freewheeling applications.
This Vishay Schottky diode is well-suited for industrial, automotive, power electronics, and semiconductor applications. For additional related products and detailed specifications, explore our Schottky Diodes & Rectifiers category on EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the Vishay V6PWL45HM3/I Schottky diode is 6 A.
This model can withstand a peak reverse repetitive voltage of 45 V.
The diode features a low forward voltage drop of 0.38 V, which helps to reduce power losses.
The Vishay V6PWL45HM3/I is packaged in a TO-252 surface mount configuration, facilitating automated PCB assembly.
It operates reliably over a wide temperature range from -40°C to 175°C.
This model has a high surge current capability, rated at 100 A for non-repetitive forward surge current.
The diode meets the automotive standard AEC-Q101, ensuring its suitability for automotive applications.
Yes, the Vishay V6PWL45HM3/I is compliant with RoHS standards.
This model is a Schottky rectifier, designed for efficient performance in power electronic circuits.
It is suitable for applications such as DC/DC converters, polarity protection, and freewheeling diodes in power supplies.
The TO-252 package has a typical height of only 1.3 mm, contributing to its low profile design.
The Vishay V6PWL45HM3/I is configured as a single diode.
