Vishay 60 V 6 A Surface Mount Rectifier & Schottky Diode TO-252 Package V6PW60HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PW60HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.46V |
Key Features
- Utilizes Trench MOS Barrier Schottky technology for high efficiency operation.
- Features a low forward voltage drop of 0.46 V to minimize power losses.
- Compact TO-252 package with a very low profile height of 1.3 mm supports automated PCB placement.
- Rated for operation from -40°C to 175°C ensuring reliability in harsh conditions.
- Peak non-repetitive forward surge current of 100 A suitable for transient handling.
- Complies with RoHS and automotive standard AEC-Q101 for quality assurance.
- Designed for low voltage, high frequency DC/DC converters, freewheeling diode and polarity protection applications.
Product Description
Vishay V6PW60HM3/I is a Schottky rectifier diode designed for surface mounting in TO-252 package. It features Trench MOS barrier technology that provides low forward voltage drop and high efficiency, ideal for industrial and automotive electronics requiring robust and reliable diode performance. The device supports a maximum repetitive reverse voltage of 60 V and continuous forward current of 6 A, accommodating demanding power management scenarios.
This component is engineered for high frequency DC/DC converters, freewheeling diodes, and polarity protection, commonly used in industrial power supplies, automotive electronic control units, telecommunications, and consumer electronics. Its compact dimensions with a height of only 1.3 mm allow for automated assembly and space saving on PCBs.
Operating in extreme temperature ranges (-40°C to 175°C), this Schottky diode maintains stable electrical characteristics and resilience under thermal stress. The peak surge current rating of 100 A ensures durability against transient spikes and surges encountered in real-world applications.
The diode complies with RoHS environmental standards and meets the automotive AEC-Q101 qualification, signaling its suitability for automotive-grade and industrial-grade electronic equipment. The product also meets MSL level 1 per J-STD-020 standards for moisture sensitivity, simplifying handling during manufacturing.
Utilizes Trench MOS Barrier Schottky technology for high efficiency and low power losses. Low forward voltage drop of 0.46 V reduces heat generation in circuits. Compact TO-252 package enables easy surface mounting and automated PCB assembly.
High operating temperature range from -40°C to 175°C supports industrial use. Surge current capability of 100 A tolerates transient conditions safely. Meets RoHS and automotive AEC-Q101 standards for quality and environmental compliance.
This Vishay diode is an excellent solution for high performance power management tasks in industrial, automotive, consumer electronics, telecommunications, and other applications requiring reliable rectification and polarity protection. Browse our extensive catalog for additional semiconductor components and related electronic parts.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the V6PW60HM3/I is 6 A.
This model has a peak reverse repetitive voltage rating of 60 V.
It operates within a temperature range of -40°C to 175°C.
The forward voltage drop of this diode is 0.46 V.
The diode comes in a TO-252 package type.
It has a peak non-repetitive forward surge current rating of 100 A.
This model complies with RoHS and meets the automotive standard AEC-Q101.
It is designed for use in high frequency DC/DC converters, freewheeling diodes, and polarity protection applications.
This component is a Schottky rectifier diode.
The country of origin for the V6PW60HM3/I is India.
The mounting type for this diode is surface mount.
This diode belongs to the eSMP series.
