Vishay 100 V 6 A Schottky Barrier Schottky DPAK Surface Mount Rectifier V6PW10HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PW10HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.58V |
Key Features
- Utilizes trench MOS barrier Schottky technology for low forward voltage drop.
- Compact DPAK (TO-252) surface mount package with low profile of approximately 1.3 mm height.
- Maximum continuous forward current of 6 A and peak non-repetitive surge current of 100 A.
- Operates reliably across a temperature range from -40°C to 175°C.
- Meets RoHS compliance and automotive standard AEC-Q101.
- Suitable for automated placement processes enhancing production efficiency.
- Low power losses and high efficiency for DC/DC converter designs.
- Designed for use in freewheeling diode and polarity protection circuits.
Product Description
Vishay V6PW10HM3/I Schottky Barrier Rectifier is a high current density surface-mount trench MOS barrier Schottky diode designed for low voltage, high frequency DC/DC converters, freewheeling diodes, and polarity protection applications.
The device features a low profile with a typical height of 1.3 mm and is housed in a TO-252 (DPAK) surface mount package ideal for automated assembly processes.
This rectifier supports a maximum continuous forward current of 6 A and can withstand peak non-repetitive forward surge currents up to 100 A, ensuring reliable operation under transient conditions.
It operates efficiently over a broad temperature range from -40°C minimum operating temperature to 175°C maximum operating temperature, making it suitable for automotive and industrial environments.
The maximum reverse repetitive voltage rating is 100 V, with a maximum forward voltage drop of 0.58 V, aiding in low power dissipation and improved efficiency in power management circuits.
This device meets strict environmental standards, including RoHS compliance and automotive standard AEC-Q101, ensuring quality and reliability in demanding applications. Utilizes trench MOS Schottky technology for performance optimization.
Compact and low-profile TO-252 (DPAK) package facilitates space-saving PCB designs. Effective in DC/DC converters, automotive electronics, telecommunications, and industrial equipment. Low forward voltage drop reduces losses, enhancing overall efficiency.
Meets moisture sensitivity level (MSL) 1 per J-STD-020 with peak reflow temperature of 260°C. Robust construction suitable for high temperature and surge conditions.
This Schottky barrier diode is widely used in electronics and electrical industrial applications where efficient rectification with low forward voltage and high speed switching is critical, including power supply circuits, automotive electronic modules, and telecommunications equipment.
Explore the Vishay product category on EnvMart to find a comprehensive range of Schottky Diodes and related semiconductor components to meet your industrial and electronic design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 6 A.
It can withstand a peak non-repetitive forward surge current of 100 A.
The maximum reverse repetitive voltage rating is 100 V.
It operates reliably over a temperature range from -40°C to 175°C.
This diode is housed in a TO-252 (DPAK) surface mount package.
The maximum forward voltage drop is 0.58 V.
Yes, it meets RoHS compliance and the automotive standard AEC-Q101.
It is suitable for use in DC/DC converters, freewheeling diodes, and polarity protection circuits.
It utilizes trench MOS barrier Schottky technology for low forward voltage drop.
This diode meets moisture sensitivity level (MSL) 1 per J-STD-020.
The typical height of the DPAK package is approximately 1.3 mm.
This model features a single diode configuration.
