Fairchild Semiconductor Line Interface LVDS Differential Driver 3V-3.6V 16mA Propagation Delay 1.5ns 5-Pin SOT-23 FIN1001M5X
Specifications
| Country of Origin | India |
|---|---|
| Brand | Fairchild Semiconductor |
| Model | FIN1001M5X |
| Mount Type | Surface |
| Output type | LVDS |
| Series | FIN1001 |
| Input Type | LVTTL |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| IC Type | DC Motor |
| Number Of Channels | 1 |
| Standards/Approvals | TIA/EIA-644 LVDS |
| Pin Count | 5 |
| Maximum Supply Voltage | 3.6V |
| Logic Function | Differential Driver |
| Minimum Supply Voltage | 3V |
| Maximum Propagation Delay Time @ CL | 1.5ns |
| Supply Current | 10mA |
| Maximum Low Level Output Current | 16mA |
Key Features
- The IC operates within a voltage range of 3V to 3.6V for efficient power usage.
- It provides a maximum low-level output current of 16mA, suitable for precise signal transmission.
- Propagation delay time is minimal at 1.5ns, enhancing performance in timing-critical applications.
- Designed for operating temperature ranges from -40°C to 125°C, ensuring reliability in harsh environments.
- The package is a space-saving 5-pin SOT-23, ideal for compact PCB designs.
- Supply current is maintained at 10mA, contributing to low power dissipation.
- The IC complies with the TIA/EIA-644 LVDS standard for electrical signaling.
- The device is not automotive standard certified but serves applications in various electronic systems.
Product Description
Fairchild Semiconductor FIN1001M5X is a high-performance line interface IC designed to implement Low Voltage Differential Signaling (LVDS) standards efficiently. The chip acts as a differential driver with a logic function tailored for LVTTL input and LVDS output. Packaged in a compact 5-pin SOT-23 surface mount package, this device is suitable for integration in space-constrained electronic components.
The device operates at a minimum supply voltage of 3V and a maximum of 3.6V, ensuring low voltage and power use while maintaining signal integrity. The maximum low-level output current rating is 16mA, which supports reliable signal transmission over differential lines.
Propagation delay is minimized to 1.5ns under typical conditions, which supports high-speed data communication tasks such as FireWire, SATA, and SCSI interfaces. The wide operating temperature range from -40°C to 125°C makes it suitable for industrial and commercial electronic applications requiring robust performance in varying thermal environments.
The FIN1001 series is compliant with the TIA/EIA-644 LVDS standard, guaranteeing compatibility and performance with other LVDS compliant devices. Although the component is not designed with automotive standards, it sees extensive use in electronic instrumentation, communication equipment, and embedded systems requiring differential signaling.
Due to its surface mount SOT-23 package and minimal pin count, the FIN1001M5X facilitates efficient PCB layout and is optimal for compact industrial and consumer electronic circuits. The device’s supply current of 10mA supports power-conscious design goals.
The IC operates within 3V to 3.6V supply voltage limits. Maximum output current capability is 16mA. Offers fast propagation delay time of 1.5 nanoseconds. Support for operating temperatures from -40°C to 125°C ensures durability.
5-pin SOT-23 package for compact design integration. Complies with TIA/EIA-644 LVDS signaling standards. 10mA supply current for energy-efficient operation. Suitable for industrial, communication, and embedded system applications.
Explore our range of semiconductor devices at EnvMart for diverse electronic component needs.
Explore more products in our Line Interface ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a supply voltage range of 3V to 3.6V.
The maximum low-level output current for this unit is 16mA.
It has a minimal propagation delay time of 1.5ns, enhancing performance in timing-critical applications.
This model is designed to operate within a temperature range from -40°C to 125°C.
It is packaged in a compact 5-pin SOT-23 surface mount package, suitable for space-constrained designs.
This device complies with the TIA/EIA-644 LVDS standard for electrical signaling.
The supply current for this model is maintained at 10mA, contributing to low power dissipation.
This differential driver supports LVTTL input type.
It features a single channel configuration.
This model is suitable for applications in electronic instrumentation, communication equipment, and embedded systems requiring differential signaling.
The logic function of this device is that of a differential driver.
The country of origin for this model is India.
