Fairchild Semiconductor LVDS Line Interface Differential Driver, 1 Channel, 3-3.6V, 16mA, SOT-23 Package FIN1001M5X
Specifications
| Country of Origin | India |
|---|---|
| Brand | Fairchild Semiconductor |
| Model | FIN1001M5X |
| Mount Type | Surface |
| Output type | LVDS |
| Series | FIN1001 |
| Input Type | LVTTL |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| IC Type | DC Motor |
| Number Of Channels | 1 |
| Standards/Approvals | TIA/EIA-644 LVDS |
| Pin Count | 5 |
| Maximum Supply Voltage | 3.6V |
| Logic Function | Differential Driver |
| Minimum Supply Voltage | 3V |
| Maximum Propagation Delay Time @ CL | 1.5ns |
| Supply Current | 10mA |
| Maximum Low Level Output Current | 16mA |
Key Features
- Operates between 3V and 3.6V supply voltage range.
- Supports low-level output current up to 16mA with fast propagation delay of 1.5ns.
- Packaged in a compact 5-pin SOT-23 surface mount package.
- Designed to operate reliably between -40°C and 125°C operating temperature range.
- Implements TIA/EIA-644 LVDS standard for high-speed data transmission.
- Features a supply current of 10mA ensuring low power consumption.
- Suitable for electronic systems requiring LVDS communication like Firewire, SATA, and SCSI interfaces.
- Not compliant with automotive standards but ideal for industrial, laboratory, and communication equipment applications.
Product Description
Fairchild Semiconductor FIN1001M5X is a low voltage differential signaling (LVDS) line interface integrated circuit, functioning as a differential driver with one channel. It supports a supply voltage range of 3 to 3.6 volts, delivering a maximum low-level output current of 16mA with a propagation delay time of only 1.5 nanoseconds. The device is packaged in a 5-pin SOT-23 surface mount package, making it well-suited for compact electronic designs.
Operating reliably within a broad temperature range of -40°C to 125°C, this LVDS line interface complies with the TIA/EIA-644 standard to ensure high-speed, low-noise data transmission over twisted-pair copper cables. These characteristics make it ideal for various applications, including Firewire, SATA, and SCSI communication systems.
This semiconductor component features a low supply current of 10mA for energy-efficient operation. Although it is not certified for automotive use, it is well-suited for industrial instrumentation, laboratory equipment, communication devices, and general electronics requiring fast LVDS line interface capabilities.
Operates with a supply voltage of 3 to 3.6 volts, meeting various low voltage system requirements. Ensures fast signal propagation with a delay time of 1.5 nanoseconds at capacitive load. Low power consumption with a supply current of 10mA.
Compact 5-pin SOT-23 package supports surface mounting to save PCB space. Wide temperature range for stable operation in harsh industrial environments. Complies with TIA/EIA-644 LVDS standards for reliable differential signaling.
Designed for industrial, laboratory, and communication interface applications.
This product is a new semiconductor component from Fairchild Semiconductor, widely regarded for performance and reliability in LVDS line interface technologies. EnvMart offers this IC as part of its comprehensive semiconductor category, making it accessible for electronic design and manufacturing projects.
Explore more products in our Line Interface ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a supply voltage range of 3 to 3.6 volts.
It supports a maximum low-level output current of 16mA.
The maximum propagation delay time is 1.5 nanoseconds at capacitive load.
It is packaged in a compact 5-pin SOT-23 surface mount package.
It operates reliably within a temperature range of -40°C to 125°C.
This device complies with the TIA/EIA-644 LVDS standard for high-speed data transmission.
It features a low supply current of 10mA, ensuring energy-efficient operation.
It is suitable for applications in industrial instrumentation, laboratory equipment, and communication devices requiring LVDS communication.
This model supports LVTTL input type.
The logic function of this unit is a differential driver.
It has one channel.
The country of origin for this semiconductor is India.
