onsemi Line Receiver Differential Input ECL Output, Surface Mount SOIC 8-Pin MC10EL16DG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.75mm |
| Length | 5mm |
| Model | MC10EL16DG |
| Width | 6.2mm |
| Mount Type | Surface |
| Output type | ECL |
| Input Type | Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| IC Type | Receiver |
| Pin Count | 8 |
| Maximum Supply Voltage | 8V |
| Logic Family | MC100 |
| Logic Function | Receiver |
| Minimum Supply Voltage | -8V |
| Maximum High Level Output Current | 50mA |
| Maximum Propagation Delay Time @ CL | 355ps |
| Supply Current | 22mA |
| Maximum Low Level Output Current | 100mA |
| Broadcom HCNW4504-300E DC Input Optocoupler, Surface, 8-Pin DIPBrand | Broadcom |
Key Features
- Part of the MC100 logic family offering high performance.
- Operates with supply voltage range from -8V to 8V.
- Maximum propagation delay of 355 picoseconds at capacitive load.
- Wide operating temperature from -40°C to 85°C for industrial applications.
- Low supply current of 22mA ensuring energy efficiency.
- Output current ratings of 50mA (high level) and 100mA (low level).
- Compact dimensions with 5mm length, 6.2mm width, and 1.75mm height.
- Surface mount SOIC package suitable for automated assembly.
Product Description
onsemi MC10EL16DG is a high-performance line receiver IC designed for differential input signals with ECL output. It belongs to the MC100 logic family and is packaged in an 8-pin SOIC surface mount device, providing compact integration for industrial and electronic applications.
This line receiver operates over a supply voltage range from -8V to 8V, with a typical supply current of 22mA, making it suitable for low-power systems. The maximum propagation delay is 355 picoseconds under capacitive loading, supporting high-speed signal processing requirements.
The device functions effectively in a wide temperature range from -40°C to 85°C, ensuring reliable operation in harsh industrial environments. Its output current capabilities include a maximum of 50mA for high-level output and 100mA for low-level output, allowing robust interfacing with subsequent circuitry.
The compact SOIC package dimensions (5mm length, 6.2mm width, and 1.75mm height) enable space-efficient PCB layouts and compatibility with automated surface mounting processes.
This line receiver is widely used in electronic components, power connectors, and semiconductor interface applications for line interface circuits requiring differential signal reception and ECL outputs. It is ideal for industrial, manufacturing, instrumentation, and high-speed digital communication systems.
Part of the MC100 logic family offering high performance. Operates with supply voltage range from -8V to 8V. Maximum propagation delay of 355 picoseconds at capacitive load. Wide operating temperature from -40°C to 85°C for industrial applications.
Low supply current of 22mA ensuring energy efficiency. Output current ratings of 50mA (high level) and 100mA (low level). Compact dimensions with 5mm length, 6.2mm width, and 1.75mm height. Surface mount SOIC package suitable for automated assembly.
Explore more semiconductor Line Interface ICs and electronic components at EnvMart for reliable and efficient industrial applications.
