DiodesZetex Current Monitor Single 3-Pin SOT-23 ZXCT1107SA-7
Specifications
| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 3mm |
| Model | ZXCT1107SA-7 |
| Mount Type | Surface |
| Series | ZXCT1107 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 3 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 2.5V |
| Supply Current | 100nA |
| GBP - Gain Bandwidth Product | 0.65MHz |
Key Features
- Operates with a supply voltage range from 2.5 V to 36 V.
- Ultra-low supply current of 100 nA ensures minimal power consumption.
- Gain bandwidth product of 0.65 MHz supports precise response in monitoring currents.
- Temperature operating range from -40°C to 125°C suitable for harsh environments.
- Automotive standard compliant with AEC-Q100 for reliable vehicle use.
- Surface mount type with a standard SOT-23 package and 3 pins for easy PCB integration.
- Provides voltage output proportional to voltage drop across low-value resistor for current sensing.
- Manufactured in China maintaining quality control standards.
Product Description
DiodesZetex ZXCT1107SA-7 is a Current Monitor amplifier designed for single-channel current sensing applications. It operates over a wide supply voltage range from 2.5 V up to 36 V with an ultra-low quiescent current of only 100 nA, making it ideal for power-sensitive electronic systems.
The device is housed in a compact 3-pin SOT-23 surface mount package measuring just 3 mm in length and 1.1 mm in height, allowing integration into space-limited PCB layouts. It features a gain bandwidth product of 0.65 MHz, delivering accurate and rapid output voltage corresponding to the current passing through a shunt resistor in a power rail.
Engineered for robust performance, the ZXCT1107SA-7 operates within an extended temperature range of -40°C to 125°C and meets the automotive quality standard AEC-Q100, ensuring reliable operation in harsh automotive and industrial environments.
This current sensing amplifier is widely used in electronic circuits requiring precise current measurement for monitoring, control, and protection functions. Typical applications include power management systems, battery monitoring, and industrial equipment.
Operates at supply voltages ranging from 2.5 V to 36 V. Ultra-low supply current of 100 nA reduces power usage. Single-channel configuration in a compact 3-pin SOT-23 package. Gain bandwidth product of 0.65 MHz for accurate current sensing signals.
Approved to automotive standard AEC-Q100 for vehicle applications. Dimensions suitable for compact electronic assemblies. Designed for precise, low-voltage drop current measurement. Manufactured in China with consistent quality assurance.
Explore a wide range of high-reliability current sensing amplifiers at EnvMart designed for industrial, automotive, and laboratory power measurement applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 2.5 V to 36 V.
It has an ultra-low supply current of 100 nA, which helps minimize power consumption.
The gain bandwidth product is 0.65 MHz, supporting precise response in monitoring currents.
It operates within an extended temperature range of -40°C to 125°C, suitable for harsh environments.
This current monitor is housed in a compact 3-pin SOT-23 surface mount package.
It is designed for single-channel current sensing applications.
The ZXCT1107SA-7 is compliant with the automotive standard AEC-Q100, ensuring reliability in vehicle applications.
The dimensions are 3 mm in length and 1.1 mm in height, making it suitable for space-limited PCB layouts.
It is widely used in electronic circuits for power management systems, battery monitoring, and industrial equipment.
It provides a voltage output that is proportional to the voltage drop across a low-value resistor used for current sensing.
It is manufactured in China while maintaining quality control standards.
This model features a pin count of 3, facilitating easy PCB integration.
