| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 3mm |
| Model | MMBT3906-7-F |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | MMBT3906 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -40V |
| Minimum DC Current Gain hFE | 30 |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | -5V |
| Maximum Collector Base Voltage VCBO | -40V |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Maximum DC Collector Current Idc | -200mA |
| Transistor Configuration | Single |
DiodesZetex MMBT3906-7-F is a high-quality small signal PNP transistor designed for low power amplification and switching applications. It supports a maximum DC collector current of 200 mA and a maximum collector emitter voltage of 40 V, making it suitable for a wide range of low voltage electronic devices.
This transistor is housed in a SOT-23 3-pin surface mount package which facilitates compact PCB designs and modern manufacturing methods. Its robust thermal properties allow operation in temperature ranges from -55°C to 150°C, ensuring reliability under harsh environmental conditions.
The MMBT3906-7-F features a transistor polarity of PNP with a single transistor configuration. It has a minimum DC current gain of 30 and a maximum power dissipation rating of 300 mW, making it ideal for signal processing and amplification tasks in electronic circuits. This device complies with the AEC-Q101 automotive standard, indicating its suitability for automotive and demanding industrial environments.
Key dimensional details include a length of 3 mm, width of 2.5 mm, and height of 1.1 mm, which enable efficient space utilization on densely populated printed circuit boards. Complies with AEC-Q101 automotive reliability standard.
Compact footprint for space-efficient circuit design. Surface mount package for automated assembly processes. Suitable for harsh temperature and industrial environments. Reliable performance in low power amplification and switching applications.
This transistor is widely used in industrial, automotive, electronic instrumentation, and communication equipment requiring compact, reliable discrete components. Its specifications allow engineers to design efficient, stable circuits with dependable transistor function.
