Nexperia Transistor NPN 100 mA 300 V 4-Pin SOT-223 PZTA42,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia Transistor NPN 100 mA 300 V 4-Pin SOT-223 PZTA42,115

Name: Nexperia Transistor NPN 100 mA 300 V 4-Pin SOT-223 PZTA42,115
Brand: Nexperia
SKU: 189651
Price: 0.22 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.8mm
Length	6.7mm
Model	PZTA42,115
Width	3.7mm
Mount Type	Surface
Series	PZTA42
Maximum Operating Temperature	150°C
Package Type	SOT-223
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	4
Maximum Collector Emitter Voltage Vceo	300V
Minimum DC Current Gain hFE	25
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	6V
Maximum Collector Base Voltage VCBO	300V
Maximum Power Dissipation Pd	1.2W
Maximum DC Collector Current Idc	100mA
Transistor Configuration	Single
Maximum Transition Frequency ft	50MHz
onsemi Bipolar Transistor, 50 mA NPN, 300 V, 4-Pin SOT-223Brand	onsemi

Key Features

Encapsulated in a compact 4-pin SOT-223 surface-mount package.
Maximum power dissipation rating of 1.2 W for efficient thermal management.
Offers a minimum DC current gain (hFE) of 25 for reliable amplification.
Wide operating temperature range from -65°C to 150°C suits harsh industrial environments.
Maximum transition frequency of 50 MHz supports high-speed switching applications.
Pin count is 4, enabling stable device connection in circuits.
Conforms to RoHS standards ensuring environmental compliance.
Manufactured in China with consistent quality.

Product Description

The Nexperia PZTA42,115 is a single NPN bipolar transistor designed for high voltage applications requiring a maximum DC collector current of 100 mA and a collector emitter voltage of up to 300 V. It features a 4-pin SOT-223 surface mount package, which provides a space-efficient footprint and reliable thermal dissipation of up to 1.2 W.

This transistor offers a minimum DC current gain of 25, ensuring adequate amplification in a range of electronic circuits. Its wide operating temperature window from -65°C to 150°C allows it to operate effectively in demanding industrial, automotive, and consumer electronics environments. The maximum transition frequency of 50 MHz provides support for moderate frequency switching and amplification applications.

The device's compact size, measuring approximately 6.7 mm in length, 3.7 mm in width, and 1.8 mm in height, makes it suitable for densely packed PCB layouts. Its RoHS compliance confirms adherence to environmentally safe manufacturing practices.

Typical applications include power switching, amplification, and signal processing in electronic components, power supplies, and other control circuits in industrial and laboratory settings.

Encapsulated in a compact 4-pin SOT-223 surface-mount package. Maximum power dissipation rating of 1.2 W for efficient thermal management. Offers a minimum DC current gain (hFE) of 25 for reliable amplification. Wide operating temperature range from -65°C to 150°C suits harsh industrial environments.

Maximum transition frequency of 50 MHz supports high-speed switching applications. Pin count is 4, enabling stable device connection in circuits. Conforms to RoHS standards ensuring environmental compliance. Dimensions approximately 6.7 mm length, 3.7 mm width, and 1.8 mm height.

Manufactured in China with consistent quality.

Find more high voltage Bipolar Transistors and components in the Electronics & Electricals category at EnvMart to meet your industrial, construction, and laboratory electronics needs.
