Nexperia Small Signal PNP Transistor BCX71H,215 3-Pin SOT-23 -100 mA -45 V 250 mW AEC-Q101 BCX71H,215

Nexperia BCX71H,215 is a high-performance small signal PNP transistor designed for use in discrete semiconductor applications requiring reliable switching and amplification. The device supports a maximum DC collector current of -100 mA and a maximum collector emitter voltage rating of -45 V, making it suitable for low power signal processing tasks in automotive, industrial, and consumer electronics.

Housed in a compact 3-pin SOT-23 surface mount package, the transistor offers space-saving benefits on printed circuit boards while maintaining a maximum power dissipation of 250 mW. This guarantees thermal stability under typical operating conditions.

The transistor configuration is single and PNP polarity, with a minimum DC current gain (hFE) of 180, facilitating efficient signal amplification. It operates reliably over an extensive temperature range from -65°C to 150°C, suitable for harsh environments including automotive applications where AEC-Q101 certification applies.

Physical dimensions characteristic of the SOT-23 package include a length of 3 mm, width of 1.4 mm, and height of 1.1 mm. Electrical ratings also include maximum collector base voltage of 45 V and emitter base voltage of 5 V. The transistor’s transition frequency of 100 MHz supports moderately high-frequency switching and amplification tasks.

BCX71H,215 transistors are ideal for use in signal processing circuits, automotive electronics, power management modules, and general-purpose electronic products demanding robust bipolar transistor performance.

This transistor has a maximum power dissipation of 250 mW ensuring reliable operation. It operates within a temperature range of -65°C to 150°C for broad industrial applications. The device offers a minimum DC current gain (hFE) of 180 with a transition frequency up to 100 MHz.

The transistor supports automotive standards with AEC-Q101 certification. Compact dimensions with a length of 3 mm, width of 1.4 mm, and height of 1.1 mm facilitate easy PCB integration. The bipolar device has a single transistor configuration and PNP polarity.

The package is surface mount type SOT-23 suitable for modern electronics manufacturing. It provides maximum collector base voltage (VCBO) of 45 V and maximum emitter base voltage (VEBO) of 5 V. Explore EnvMart’s broad selection of Bipolar Transistors and Nexperia components for your next electronics design or manufacturing project.
