Vishay 1, 9.1 V Zener Diode Single 500 mW 2 % Surface Mount 2-Pin SOD-80 TZMB9V1-GS08

Free Delivery in India | Lowest Global Shipping Charges

Vishay 1, 9.1 V Zener Diode Single 500 mW 2 % Surface Mount 2-Pin SOD-80 TZMB9V1-GS08

Name: Vishay 1, 9.1 V Zener Diode Single 500 mW 2 % Surface Mount 2-Pin SOD-80 TZMB9V1-GS08
Brand: Vishay
SKU: 218059
Price: 0.06 USD
Availability: InStock



Category Zener Diodes Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Length	3.7mm
Model	TZMB9V1-GS08
Mount Type	Surface
Series	TZM
Maximum Operating Temperature	175°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	2μA
Nominal Zener Voltage Vz	9.1V
Zener Type	Voltage Regulator
Maximum Zener Impedance	50Ω

Key Features

Designed as a voltage regulator with a 2% tolerance to maintain voltage stability.
Package type SOD-80 with 2 pins supports surface mounting on PCBs.
Maximum power dissipation of 500 mW ensures suitable performance for low power applications.
Operates reliably over the temperature range of -65°C to 175°C meeting automotive AEC-Q101 standard.
Maximum zener impedance is 50 ohms which ensures stable voltage regulation.
Test current of 5 mA is used to characterize device performance.
Maximum reverse leakage current of 2 µA minimizes unwanted current flow in reverse bias conditions.

Product Description

Vishay TZMB9V1-GS08 is a high quality, surface mount Zener diode designed for voltage regulation and protection in electronic circuits. It features a nominal zener voltage of 9.1 V with ±2% tolerance, making it suitable for precise voltage stabilization tasks.

The device can handle a maximum power dissipation of 500 mW and is enclosed in a compact SOD-80 package with 2 pins, facilitating surface mounting on printed circuit boards. It operates efficiently with a test current of 5 mA and has a maximum zener impedance of 50 ohms, contributing to stable voltage regulation performance.

Thermally robust, the diode supports a wide operating temperature range from -65°C to 175°C, ensuring reliability under harsh conditions, including automotive applications validated by AEC-Q101 certification. The maximum reverse leakage current is limited to 2 µA, reducing leakage losses and improving circuit efficiency.

This component's length of 3.7 mm allows easy integration into compact electronic assemblies. Vishay's TZM series Zener diodes are designed for industrial, automotive, telecommunications, and power supply applications where voltage regulation and transient voltage suppression are critical.

Single diode configuration for straightforward application. Surface mount technology optimizes PCB space. Voltage regulator type for stable voltage output. Complies with RoHS standards ensuring environmental safety. Automotive standard AEC-Q101 suitability for high-reliability systems.

Ideal for use in power supplies, automotive electronics, and industrial control circuits.

Choose the TZMB9V1-GS08 for dependable, precision voltage regulation in your designs. Explore more semiconductor products in the Zener Diodes category on EnvMart for diverse electronic components fit for your technical needs.
