Samtec TMM Series Straight Through Hole Pin Header 24 Contacts 2 mm Pitch 2 Row Unshrouded TMM-112-01-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 281V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | TMM-112-01-L-D |
| Mount Type | Through Hole |
| Special Features | FleXYZ™ provides design flexibility in all three axes up to four rows wide and 200 pins |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TMM |
| Termination | Through-hole, surface mount |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Contact System | .020" (0.50 mm) square post |
Key Features
- Constructed with liquid crystal polymer housing for durability.
- Phosphor bronze contacts plated with gold ensure reliable conductivity.
- Designed for board-to-board and wire-to-board connector systems.
- Features solder termination type suited for through-hole mounting.
- Operates over a temperature range from -55°C to 125°C.
- Supports a maximum current of 3.2 A and voltage up to 281 V.
- Offers flexible design with FleXYZ™ allowing adjustment in three axes.
- Contact system uses 0.020" (0.50 mm) square posts for secure connections.
Product Description
Samtec TMM-112-01-L-D is a high-quality straight through hole pin header featuring 24 contacts arranged in 2 rows with a 2 mm pitch. It comes with an unshrouded design ideal for various PCB header applications in electronics assembly.
The housing is made from liquid crystal polymer, providing excellent durability and mechanical strength. Contact materials include phosphor bronze with gold plating, ensuring long-term reliable electrical connections and resistance to corrosion.
This pin header supports both board-to-board and wire-to-board connector systems and employs a solder termination type designed for through-hole mounting on PCBs. The component operates in a wide temperature range from -55°C to 125°C, suitable for demanding industrial environments. It supports a maximum current rating of 3.2 amperes and voltage of up to 281 volts.
One of the key features includes Samtec's FleXYZ™ technology, which offers design flexibility by allowing adjustments in all three axes and can accommodate up to four rows wide and 200 pins, enabling versatile layout options.
The contact system uses 0.020" (0.50 mm) square posts for secure and efficient connectivity. The pin header is male contact gender, unshrouded for easy access and installation in electronic devices.
This product is ideal for industrial, manufacturing, and electronics prototyping environments requiring reliable pin header connectors that maintain signal integrity and mechanical strength over time.
Constructed with liquid crystal polymer housing for durability. Phosphor bronze contacts plated with gold ensure reliable conductivity. Designed for board-to-board and wire-to-board connector systems. Features solder termination type suited for through-hole mounting.
Operates over a temperature range from -55°C to 125°C. Supports a maximum current of 3.2 A and voltage up to 281 V. Offers flexible design with FleXYZ™ allowing adjustment in three axes. Contact system uses 0.020" (0.50 mm) square posts for secure connections.
Explore more high-quality PCB connector options with Samtec products available through EnvMart for your electronics manufacturing and design needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 3.2 A and a voltage of up to 281 V.
It operates over a temperature range from -55°C to 125°C, making it suitable for demanding environments.
The housing is made from liquid crystal polymer, while the contacts are phosphor bronze plated with gold for reliable conductivity.
This pin header features 24 contacts arranged in 2 rows with a pitch of 2 mm.
It features a solder termination type designed for through-hole mounting on PCBs.
It is designed for both board-to-board and wire-to-board connector systems.
The contact gender of this model is male, and it has an unshrouded design for easy access.
FleXYZ™ provides design flexibility, allowing adjustments in all three axes and accommodating up to four rows wide and 200 pins.
The contact system uses 0.020" (0.50 mm) square posts for secure connections.
This model has a straight orientation, suitable for various PCB applications.
The country of origin for this pin header is India.
This pin header is part of the TMM series by Samtec.
