Samtec TFM Series Straight Surface PCB Header, 10 Contact(s), 1.27 mm Pitch, 2 Row, Shrouded TFM-105-02-L-D-A

Samtec TFM-105-02-L-D-A is a high-reliability PCB Header featuring a straight surface mount design with 10 contacts arranged in two rows with a 1.27 mm pitch. This shrouded header is engineered for board-to-board and wire-to-board applications, making it ideal for industrial, electronic component manufacturing, and high-precision assembly environments.

The header uses a robust multi-finger Beryllium Copper (BeCu) contact system offering long service life and excellent electrical performance. Contacts are made of Phosphor Bronze plated with Gold to enhance conductivity and minimize corrosion. The housing utilizes Liquid Crystal Polymer, providing excellent mechanical strength and thermal stability for operation from -55°C to 125°C.

Designed for surface mount technology (SMT) with solder termination, this male contact header offers versatile mounting options including through-hole and surface mount, supporting complex PCB configurations. The shrouded design facilitates blind mating, reducing the risk of misalignment during assembly and enhancing connection reliability in demanding industrial environments.

The header supports a current rating of 3.2A and a voltage rating of 250V, suitable for a wide range of electronic applications. Special features include screw down, weld tab, and solder nail options to meet rugged operational requirements.

Manufactured in the United States, this Samtec PCB Header conforms to precise engineering standards and is recommended for use in industrial electronics, power distribution, and high-reliability signal transmission.

Offers a current rating of 3.2A for robust electrical performance. Housing crafted from Liquid Crystal Polymer for durability. Contact material is Phosphor Bronze plated with Gold for superior conductivity and corrosion resistance.

Designed for surface mount with solder termination and male contact gender. Operates reliably between -55°C and 125°C. Supports both board-to-board and wire-to-board connector systems. Features a multi-finger BeCu contact system for high reliability and cycle life.

Shrouded body enables blind mating to prevent connection errors. Voltage rating of 250V for industrial applications. Manufactured in the United States ensuring quality standards. Explore more high-quality PCB Headers and connectors in the Electronics & Electricals category on EnvMart to meet your industrial and manufacturing needs.
