Nexperia 60 V 2.8 A Schottky Diode 2-Pin SOD-123W PMEG6020ETR,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 2.8mm |
| Model | PMEG6020ETR,115 |
| Width | 1.9mm |
| Mount Type | Surface |
| Series | PMEG6020ETR |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-123W |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 2.8A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 100mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 530mV |
| Peak Reverse Recovery Time trr | 8.5ns |
| Average forward current | IF(AV) ≤ 2 A |
| Reverse voltage | VR ≤ 60 V |
Key Features
- Surface mount device (SMD) in compact SOD-123W package for space-saving.
- Low forward voltage drop of 530 mV minimizes power loss.
- AEC-Q101 qualified, ensuring automotive grade reliability.
- High temperature tolerance up to 175°C operating temperature.
- Integrated guard ring for stress protection and enhanced durability.
- Peak reverse current of 100 mA and peak surge current of 50 A for robustness.
- Extremely fast reverse recovery time of 8.5 ns for efficient switching.
Product Description
Nexperia PMEG6020ETR,115 is a medium power Schottky barrier diode with a maximum continuous forward current of 2.8 A and repetition reverse voltage of 60 V, designed in a 2-pin SOD-123W surface mount package. It features a low forward voltage drop of 530 mV and fast recovery time, making it suitable for high efficiency power rectification in demanding industrial and automotive applications.
This diode is AEC-Q101 qualified, ensuring it meets rigorous automotive standards for quality and reliability. Its planar MEGA (Maximum Efficiency General Application) design with an integrated guard ring provides stress protection and high durability in harsh environments.
Operating temperature ranges from -55°C to 175°C, allowing use in a wide range of temperature conditions found in industrial, automotive, and power management systems. The low leakage current of 100 mA peak reverse current and high peak non-repetitive surge current of 50 A make it robust for transient conditions.
The compact SOD-123W package with dimensions 2.8 mm long, 1.9 mm wide, and 1.1 mm high enables space savings on printed circuit boards, making it ideal for compact electronic designs, including power supply circuits, battery-powered devices, and automotive electronics.
Surface mount SOD-123W package enables compact board design. Low forward voltage reduces power dissipation improving system efficiency. AEC-Q101 qualified for automotive and industrial reliability. Wide operating temperature range suitable for industrial use.
High peak surge current capacity for transient robustness. Fast reverse recovery time minimizes switching losses. Integrated guard ring protects against stress damage. Compact dimensions support dense PCB layouts.
This Nexperia diode is ideal for use in power management, automotive electronics, industrial control, and other applications requiring efficient low forward voltage rectification and reliable performance at high temperatures. Explore more in our electronics catalog for compatible components and solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 2.8 A.
This diode has a peak reverse repetitive voltage rating of 60 V.
The dimensions of the SOD-123W package are 2.8 mm in length, 1.9 mm in width, and 1.1 mm in height.
The operating temperature range for this model is from -55°C to 175°C.
The maximum forward voltage drop for this diode is 530 mV.
The reverse recovery time for this model is 8.5 ns.
The peak non-repetitive forward surge current rating is 50 A.
Yes, this diode is AEC-Q101 qualified, ensuring it meets automotive standards for quality and reliability.
This model uses surface mount technology (SMD) for mounting.
The peak reverse current rating for this diode is 100 mA.
This diode is suitable for power management, automotive electronics, and industrial control applications.
The diode configuration for this model is a single diode.
