Vishay Three Phase Bridge Rectifier, 1600 V Peak Reverse Repetitive Voltage, 470 A Peak Surge Current, PCB VS-100MT160PAPBF

Free Delivery in India | Lowest Global Shipping Charges

Vishay Three Phase Bridge Rectifier, 1600 V Peak Reverse Repetitive Voltage, 470 A Peak Surge Current, PCB VS-100MT160PAPBF

Name: Vishay Three Phase Bridge Rectifier, 1600 V Peak Reverse Repetitive Voltage, 470 A Peak Surge Current, PCB VS-100MT160PAPBF
Brand: Vishay
SKU: 214503
Price: 59.69 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	16mm
Length	63.5mm
Model	VS-100MT160PAPBF
Width	32.5mm
Mount Type	PCB
Series	VS-100MT
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	MT PA
Minimum Operating Temperature	-40°C
Number of Phases	3
Pin Count	8
Peak Reverse Repetitive Voltage Vrrm	1600V
Peak Reverse Current Ir	5mA
Peak Non-Repetitive Forward Surge Current Ifsm	470A
Forward Current If	100A
Peak Forward Voltage Vf	1.51V

Key Features

Features a low profile MT PA package for space-saving PCB designs.
Supports a forward current of 100 A with a maximum operating temperature of 150°C.
Operates reliably between -40°C and 150°C.
Includes 8 pins configured for single phase bridge rectification.
Provides peak forward voltage of 1.51 V ensuring efficient rectification.
Maximum peak reverse current is 5 mA, minimizing leakage.
Designed for three phase full-wave rectification applications.
Ideal for industrial and power electronics requiring robust and compact rectifiers.

Product Description

Vishay VS-100MT160PAPBF is a three phase Bridge Rectifier known for its compact size and robust performance. It features a low profile MT PA package with 8 pins for easy PCB mounting, making it suitable for compact industrial and power electronic designs.

This rectifier converts alternating current (AC) input into direct current (DC) output with full-wave rectification, providing consistent polarity output. It supports a forward current of 100 A and handles peak reverse repetitive voltages up to 1600 V, ensuring durability in demanding electrical environments.

The device can operate over a broad temperature range from -40°C to a maximum of 150°C, making it reliable under harsh conditions. Its peak surge current rating of 470 A provides transient stability, while a peak forward voltage of 1.51 V optimizes efficiency by minimizing power loss.

The rectifier's low leakage current at 5 mA peak reverse current enhances energy efficiency. With a length of 63.5 mm, width of 32.5 mm, and height of 16 mm, it provides a compact footprint ideal for PCB layouts requiring space savings.

Low profile MT PA package accommodates direct mounting to heat sinks. Three phase configuration enables full-wave rectification with high reliability. Designed for use in industrial machines, power supplies, HVAC systems, and manufacturing equipment.

Sturdy construction supports stable operation at high temperatures and currents. Contributes to improved production efficiency in electrical and electronic system designs.

Choose Vishay VS-100MT160PAPBF for high-performance, reliable bridge rectification in demanding industrial and commercial electronics applications. Browse more Vishay semiconductor components at EnvMart for comprehensive solutions tailored to your power electronics needs.
