Taiwan Semiconductor 150 V 1 A Schottky Diode Surface Mount DO-214AC SS115

Taiwan Semiconductor SS115 Schottky Diode is a discrete semiconductor device designed for efficient rectification and low power loss in electrical and electronic circuits. Featuring a surface mount DO-214AC package, this diode supports a maximum continuous forward current of 1 ampere and a peak reverse voltage of 150 volts, making it suitable for moderate power applications including power supplies, switching regulators, and automotive electronics.

The low forward voltage drop characteristic of Schottky diodes reduces power dissipation, improving system efficiency and thermal performance. Its compact form factor, with dimensions measuring 4.6 mm in length, 2.83 mm width, and 2.3 mm height, allows high-density PCB assembly in industrial, automotive, and consumer electronics.

This diode operates effectively over a wide temperature range from -65°C to 150°C, ensuring durability in harsh environmental conditions. It also features a peak non-repetitive forward surge current capacity of 30 amperes, suitable for transient load handling during startup or fault conditions. The minimal peak reverse current of 100 microamperes helps maintain circuit integrity and reduces leakage losses.

The SS115 is commonly used in power rectification, voltage clamping, and reverse polarity protection applications within industrial automation, HVAC controls, telecommunications, and battery management systems. Its surface mount design ensures compatibility with automated soldering processes and compact PCB layouts.

Schottky barrier with low forward voltage drop enhances efficiency. 1 A continuous forward current suitable for medium power circuits. 150 V peak reverse voltage for reliable reverse voltage tolerance. Compact DO-214AC package for surface mount technology applications.

Wide operating temperature range from -65°C to 150°C. Low peak reverse current of 100 μA minimizes leakage losses. Peak forward surge current of 30 A enables handling of transient currents. 2-pin single diode configuration for easy PCB integration.

This Taiwan Semiconductor Schottky diode offers robust and efficient rectification solutions for demanding industrial, laboratory, manufacturing, and commercial electronic systems. Its proven reliability and compact package support a wide array of modern electronic designs.
